SUGGESTED SPEED SETTING
As tested at the factory, the following are suggested setting of speeds and time delays:
DIAL SETTING
*
Conveyor Speed _______________
*
Turning Unit _______________
*
Applier _______________
Product Spacer _______________
These settings will product approximately _______________
parts per minute production
If speed of any of the above “*” are changed for any reason, comparable changes in the other
settings should be made.
The above speed settings are provided only as guidelines for start-up and may need to be changed
because of variables in voltages, area to area, and other variables over which we have no control.
SETUP INSTRUCTIONS
