Specifications

General

Channels:

Transmit: 54
Receive: 77 Marine/10 Weather

Controls:

On-Off/Volume, Squelch

Status Indicators:

TX LED (transmit), SCAN, TRI, U, I, C, HI, LO,

MEM, and WX symbol on LCD Panel

Channel Display:

LCD (Dual 7 segment)

Selector Switch:

Channel Selector switch

Buttons:

WX, 16/9, MEM, H/L, and STEP

Connectors:

Antenna, remote speaker, and DC power

Size:

2 1/5"H x 6 2/5"W x 8"L

Weight:

2.4 lbs

Supply Voltage:

13.8V DC negative ground

Standard Accessories:

Mounting bracket and hardware, DC power cord,
microphone hanger, spare fuse

Antenna Impedance:

Ω

nominal

Microphone:

Rugged 1k

Ω

condenser mic element with

coiled cord

Speaker:

1.82 inch, 8

Ω

Operating Temperature Range:

– 20°C to +50°C (– 4°F to +122°F)

Shock and Vibration:

Meets or exceeds EIA standards, RS152B
and RS204C

FCC Approvals:

Type accepted under part 80 of the Rules;

meets Great Lakes Agreement and party
boat requirements

Transmitter

Power Output:

1 watt or 25 watt (switch selectable)

Power Requirement:

Not rated on LO;

25 watts output: [email protected] DC

Modulation:

5 kHz deviation (FCC designator F3E)

Hum and Noise Signal-to-Noise:

42 dB@300 HZ, 3kHz (nominal)

Audio Distortion:

Less than 3% with 3 kHz deviation with 1000 Hz
modulating frequency (nominal)

Spurious Suppression:

– 56 dB @ 1 watt, – 65 dB @ 25 watts

Output Power Stabilization:

Built-in automatic level control (ALC)

Frequency Range:

156 to 158 mHz

Frequency Stability:

1.58 kHz @ – 20°C to +50°C

Receiver

Frequency Range:

156 to 163 MHz

Sensitivity:

0.25

V for 12 dB SINAD

0.35

V for 20 dB S/N

Circuit:

Dual Conversion Super Heterodyne PLL

Squelch Sensitivity:

0.5

v Threshold

Spurious Response:

60 dB

Adjacent Channel Selectivity:

60 dB @

25 kHz

Audio Output Power:

3.0 watts (10% Distortion)

Power Requirement:

230 mA @ 13.8V DC squelched

0.7A @ 13.8V DC at maximum audio output

IF Frequencies:

1st - 16.9 mHz
2nd - 455 kHz
