Specifications

AU03-208

Alliance Laundry Systems

Shepard Street, Ripon, WI 54971 Telephone: 1-800-587-5458

www.uniwash.com

UX18

UX25

UX35

UX55

UX75

UX100

UX135

UX165

Capacity (lb/kg)

18 (8)

25 (11)

35 (16)

55 (25)

75 (34)

100 (45)

135 (61)

165 (75)

Width (in/mm)

26” (660)

30.8” (783)

35.4” (900)

41.8” (1060)

47.3” (1200)

51.2” (1300)

Depth (in/mm)

30.7” (780)

34.3” (870)

37.8” (960)

40” (1016)

46” (1168)

52.4”(1330)

59.1” (1500)

63.8” (1621)

Height (in/mm)

40.6” (1031)

40.6” (1031

47” (1194)

60.8” (1544)

61.4” (1560)

75.6” (1920)

82.7” (2100)

Cylinder Diameter (in/mm)

20.9” (530)

25.6” (650)

29.5” (750)

33.5” (850)

38.6” (980)

43.1” (1095)

Cylinder Depth (in/mm)

13.6” (345)

17.3” (440)

19.7” (500)

20.9” (530)

21.1” (537)

23.5” (597)

30.5” (775)

Cylinder Volume (cu.ft/litr)

2.7 (76)

3.4 (97)

5.9 (167)

8.3 (234)

10.8 (305)

15.9 (451)

20.7 (585)

25.8” (7.31)

Door Opening Size (in/mm)

11.8” (300)

15.6” (395)

19.7” (500)

24.5” (622)

Door Bottom to Floor (in/mm)

11” (279)

15.6” (395)

22” (559)

25.5” (648)

28” (711)

Wash Speed (rpm)

10-50

Distribution Speed (rpm)

100

Extract Speed (rpm)

85-1000

100-1000

250-1000

250-800

250-750

Extract G-Force (rpm)

19-296

23-363

26-418

30-475

34-350

344

Water Inlet Conn. (in/mm)

3 x .75 (19)

4 x .75 (19)

Steam Inlet Conn. (in/mm)

.375 (9.5)

Drain Connection Size (in/mm) 2” (51)

2” (51)

3” (75)

4” (102)

Motor Size (HP/kw)

1 (.75)

2 (1.5)

4 (3)

5.25 (4)

7.4 (5.5)

10 (7.5)

15 (11.5)

Voltage/Hz/Phase Non-heat

200-240/50-60 1/3 200-240/50-60 1/3 200-240/50-60 1/3 200-240/50-60 1/3 200-240/50-60/3

200-240/50-60/3

Circuit Breaker-FLA

15-6

15-12

20-12

25-17

30-17

40-25

Voltage/Hz/Phase* Elect. heat

200-240/50-60/3

N/A

Circuit Breaker-FLA

30-28

30-29

50-41

60-58

90-88

Voltage/Hz/Phase* Non-heat

380-415/50-60/3

Circuit Breaker-FLA

16-6

16-12

20-17

25-17

25-20

Voltage/Hz/Phase Elect. heat

380-415/50-60/3

N/A

Circuit Breaker-FLA

20-17

20-18

30-26

40-36

63-55

Voltage/Hz/Phase*

440-480/50-60/3

Circuit Breaker-FLA

15-6

15-12

20-17

25-17

25-20

Shipping Dimensions (in/mm)

H: 44.9 (1140) H: 48.8 (1240) H: 51.6 (1310) H: 65 (1650)

H: 68.1 (1730) H: 79.1 (2010) H: 79.1 (2010) H: 89.5 (2273)

W: 28.8 (732)

W: 33.5 (850)

W: 40.2 (1020) W: 45.7 (1160) W: 51.2 (1300) W: 51.2 (1300) W: 55.4 (1407)

D: 32.8 (832)

D: 37.4 (950)

D: 43.3 (1100) D: 45.3 (1150) D: 48.4 (1230) D: 56.3 (1430) D: 64.2 (1630) D: 71.2 (1808)

Net Weight (lb/kg)

502 (236)

531 (241)

765 (347)

1247 (570)

1907 (865)

3351 (1520)

3626 (1645)

4630 (2100)

Shipping Weight (lb/kg)

624 (283)

639.5 (290)

1030 (467)

1380 (630)

2194 (995)

3741 (1697)

4017 (1822)

5181 (2350)

Agency Approvals

CE, ETL, ETLc CE, ETL, ETLc CE, ETL, ETLc CE, ETL, ETLc CE, ETL, ETLc CE, ETL, ETLc CE, ETL, ETLc CE, ETL, ETLc

* Special order may require longer time, check with factory.

Voltages above or below listed may require a buck-boost transfer.

Due to continuous product improvement, design and specifications subject to change without notice. Features and certifications may vary by model.

Components:

Top Supply Compartment
(18 - 75 lb)

2. Controls

3. Cold Water Inlet

4. Hot Water Inlet

5. Cold Water Inlet

6. Vacuum

Breaker

7. Electrical

Connection

8. Drain

Outlet

Front Supply Compartment
(100 - 165 lb)

10. Supply Inlet
11. Water Inlet for Supply Box

(100 - 165 lb)

3 4 5
