Parts list, Hardware, Exploded view – Uniflame WAD792SP User Manual
Page 3: Tools required for assembly (included), Tools required for assembly (not included)
Contact 1.800.762.1142 for assistance. Do not return to place of purchase.
page no.
3
Parts List
1
Handle
55-05-530
2
Spark Guard
55-05-531
3
Wood Grate
55-05-532
4
Base Ring (4)
55-05-533
5
Bowl
55-05-534
6
Leg (3)
55-05-535
Hardware
A
Screw
M5x10 Nickel Plated
20 pcs
B
Bolt
M6x10 Nickel Plated Column Hex Head
9 pcs
C
Nut
M6 Nickel Plated
1 pcs
Exploded View
1
2
3
Tools Required for Assembly (Included)
Allen Wrench
1 pc
Tools Required for Assembly (Not Included)
#2 Phillips Head Screwdriver
1 pc
4
5
4
4
6
4
