UE3G2L036C61TMB
Overload Capacity 125% for 30 secs, 150% for 10 secs
Crest Factor 3.0 at full load
Frequency 50/60 Hz Auto Sensing
Frequency Regulation ± 0.5Hz/± 1.0Hz/± 1.5Hz (authorized service center selectable only)
Wave Form Sine wave, Zero Transfer Time
Load Power Factor 0.85
Efficiency AC to AC Greater than 83%
Common Mode Noise Less than 0.5 Vrms
BATTERY DC Voltage 216V
Backup Time 10 min (full load) 30 min (half load)
Battery type Enersys NPX-35 Flame Retardant Lead Acid 9Ah/12V Part #: 51896
Number of batteries Pack 3 (Six batteries in each pack)
Recharge time <12 hours to 90%
PHYSICAL Interface RS-232, Dry Contact Connectivity, External Battery Connectivity
Input Hardwire Input
Output Hardwire Output
Dimensions WxDxH (mm) 838x254x711
Ship Dimensions WxDxH (mm) 965x432x940
Dimensions W x D x H (inch) 33x10x28
Ship Dimensions WxDxH (inch) 38x17x37
Weight kg (lb) 120.2 (265)
Ship Weight kg (lb) 127 (280)
OPTION External Matching Battery Cabinet Single - 70 Mins, Double - 140 Mins. Max Two Cabinets. Part #: UE3-BC-0650
Network Interface Card RemotEye II - Part #: RMTI-INT-R25
Environmental Monitoring Device Part #: RMTI-EMD-HT
ENVIRONMENT Operating Ambient Temperature 0 ~ 40 o C (32 ~ 104 o F)
Recommended Temperature +15 o C ~ 25 o C
Storage Temperature -20 o C ~ 40 o C
Humidity 30-90%, Non-Condensing
Audible Noise 50dB (A) maximum @ 1 meter from Front Panel
Altitude 3300 ft (1,000 m) above sea level
CONFORMANCE Regulatory Approvals UL, CUL, ISO 9001, NEMA/PEI-1993
WARRANTY Three years on electronics
Two years full replacement on battery (See Toshiba warranty policy for full details)
