REAR PANEL JACKS
12
ቧ
Component: Y-P
B
P
R
Inputs
Inputs 4 and 5 provide Y-P
B
P
R
jacks for connecting equipment with this capability, such as a DVD player or Set Top Box. You may
use standard video signal for INPUT:4 and 5.
NOTES: 1. Your component outputs may be labeled Y, B-Y, and R-Y. In this case, connect the components B-Y output to the TVÕs PB input and
the components R-Y output to the TVÕs PR input.
2. Your component outputs may be labeled Y-CBCR. In this case, connect the component CB output to the TVÕs PB input and the
component CR output to the TVÕs PR input.
3. It may be necessary to adjust TINT to obtain optimum picture quality when using the Y-PBPR inputs. (See pages 53 and 54)
4. To ensure no copyright infringement, the MONITOR OUT output will be abnormal, when using the Y-PBPR jacks.
5. When using Y-PBPR input, only 480i signal can be viewed as a sub-picture.
6. Input 4 and 5 (Y/VIDEO) can be used for standard video input.
