TORS
1 Antenna
2 PTT(Push-To-Talk) Key
3 Monitor Key
4 Keylock/Call Key
5 Memory/Scan Key
6 Channel/ Transmit Power Key
7 Speaker
8 Headset Jack
9 Select/Power On-Off Key
10 Volume/Select Up Key
11 Volume/Select Down Key
12 Microphone
13 Receive Indicator
14 Transmit Indicator
15 Channel Indicator
16 DCS ON Indicator
17 Scan Indicator
18 Memory Indicator
19 Priority Channel Indicator
20 CTCSS ON Indicator
21 Battery Level Indicator
22 HI Transmit Indicator
23 Lo Transmit Indicator
24 CTCSS and DCS Code/Volume Level Indictor
25 Volume Setting Indicator
26 VOX Indicator
27 Busy Channel Lockout Indicator
28 Keypad Lock Indicator
29 Charging LEDs
(1)
29
10
11
12
CONTROL & INDICATORS
INCLUDED IN YOUR PACKAGE:
•
Radio (2)
• Operating Guide
• Belt Clip (2)
• VOX Earset
• Carry Case
uh064sx-2
• Charging Cradle with AC Adaptor
• NiMH Battery Pack (2)
• VOX Headset (2)
• External Speaker Mic (2)
OPTIONAL ACCESSORIES
txp
mic
