USSC 21
Parts List model 5500/5500M/5500XL
Item Part No. Title Qty.
1 86624 Burnpot Assembly 1
2 86625 Housing Assy, Burnpot 1
3 86628 Weldment, Exhaust Duct 1
4 86633 Weldment, Igniter Tube 1
5 80481 Igniter Cartridge 1
6 25506 Weldment, Door Hinge 1
7 69512 Door Assembly 1
8 69518 Hopper Assembly (5500) 1
- 69522 Hopper Assembly (5500XL) 1
9 891164 Weldment Auger Housing 1
10 69513 Assy., Bushing Retainer Bottom 1
10.1 891190 Plate, Bottom Bushing 1
10.2 891132 Bushing 1
10.3 83534 Retaining Ring 1
11 69514 Assy., Bushing Retainer Top 1
11.1 891189 Plate, Top Bushing 1
11.2 891132 Bushing 1
11.3 83534 Retaining Ring 1
12 891161 Weld., Bot. Plate Retainer 1
13 83543 6-32 x 3/8 Machine Screw 2
14 83356 10-32 Hex Nut 4
15 83299 6-32 Hex Nut 2
16 891195 Bracket, Drive Motor 1
17 25498 Weldment, Top Lid 1
18 25511 Weld, Left Side Cabinet (5500) 1
- 25515 Weld, Left Side Cabinet (5500XL) 1
19 80558 Circuit Board Assembly 1
20 80480 Thermistor 1
21 88117 Gasket, Exhaust Duct 1
22 88100 Gasket, Exhaust Blower 1
PARTS LIST
Item Part No. Title Qty.
23 80473 Blower, Exhaust 1
24 88118 Gasket, Igniter Flange 1
25 891169 Hose, Heater 1.5in
26 891141 Auger 1
27 80488 Drive Motor 1
28 83529 Hairpin 1
29 891180 Cover, Auger 1
30 83297 8-32 Hex Nut 4
31 891187 Bracket, Pressure Switch/PCB 1
32 80549 Pressure Switch 1
33 89586 Nipple 1
34 891148 Handle, Plastic 1
35 891121 Silicone Tube 3 in.
36 25512 Side, Right Cabinet (5500) 1
- 25516 Side, Right Cabinet (5500XL) 1
37 25510 Panel, Access 1
38 80472 Blower, Distribution 1
39 88106 Gasket, Distribution Blower 1
40 25513 Cleanout, Ash 2
41 80491 Microswitch 1
42 88119 Insulation, Blanket 2
43 80462 Receptacle, 3 Prong 1
44 80461 Power Supply Cord 1
45 83516 #4-40 Machine Screw 2
46 83542 #4-40 Nylon Lock Nut 2
47 89390A Rubber Grommet 1
N/S 80548 Wiring Harness 1
