16

2115WC and 2115WCOL, 2175WC and 2175WCOL

Door Reversal

Figure 18

All U-Line black units may be left- or right-hand opening.
Stainless steel unit doors cannot be reversed. The doors
are easily reversed by moving the hinge hardware to the
opposite side. The top hinge hardware will be used on the
bottom of the other side and the bottom hinge hardware
will be used on the top of the other side (Figure 18).

To reverse the door:

Figure 19

1. Remove top hinge screw pin (Figure 19, 1) from door

using a Phillips screwdriver. Remove door by tilting
forward and lifting off bottom hinge pin.

Figure 20

2. Remove plastic screw plugs (three each, top and

bottom) (Figure 20, 1) from new hinge location. Do
not discard.

3. Remove top hinge (three screws) (Figure 19, 2) and

reinstall hinge screw pin (Figure 19, 1).

Figure 21

4. Install the removed top hinge mount on opposite side

BOTTOM (Figure 21).

Figure 22

ULIN_0015_A

1

2

ULIN_0003_A

1

ULIN_0002_A

1

ULIN_0005_A

1

ULIN_0004_A
