RING TIME
REC TIME
2/4/TS
ANN/4/1
38
44
45
46
47
42
43
41
48
49
39
40
50 51 52 53
1. Handset antenna
2. Headset cover
3. Handset battery compartment
4. Handset ring switch
5. Handset speaker
6. LCD display
7. Talk key
8. Volume/Cursor down/
character select key
9. Caller ID key
10. Tone/Backspace key
11. Redial/Pause key
12. Select/Channel key
13. Handset microphone
14. Volume/Cursor up/
Character select key
15. Flash key
16. Memory key
17. Delete key
18. Cursor forward key
19. Mute/Ring key
20. Intercom key
21. Handset contact
22. Base microphone
23. Speaker LED
24. Status LED
25. Handset clip storage
26. Clock key
27. Pin code key
28. Delete key
29. Greeting key
30. Repeat key
31. Skip key
32. Voice memo record key
33. Base contact
34. Tone key
35. Mute key
36. Speaker key
37. Page/Intercom key
38. Base speaker
39. Volume down key
40. Volume up key
41. LED display
42. Play/Stop key
43. Base antenna
44. Answer on/off key
45. Memory key
46. Redial/Pause key
47. Flash key
48. Rec time switch
49. Ring time switch
50. Ring volume switch
51. Pulse-Tone switch
52. DC power input
53. Phone jack
