Installing.the.GPS.Device.in.Your.Vehicle.

Windshield Mounting
When you install the device for the first time, attach the

device.to.the.support.arm.before.attaching.the.arm.to.your.

vehicle.windshield.

Note:.Before.attaching.the.suction.cup,.clean.the.inside.

of.your.windshield.with.a.standard.window.cleaner.and.a.

lint-free.cloth..

Extend.the.GPS.antenna.and.insert.the.hooks.on.the.

support.arm.into.the.holes.on.the.bottom.of.the.Device.
Squeeze.the.locking.tabs.together..Swing.the.top.of.the.

support.arm.into.the.back.of.the.device..Release.the.

locking.tabs..
Place the suction cup flat against the windshield, and

adjust.the.position.so.you.can.easily.see.the.display.screen.

but.your.driving.view.is.not.obstructed..Flex.the.goose-

neck.support.arm.until.the.display.is.in.the.right.position.

1.

2.

3.

Press.the.suction.cup.

firmly against the

windshield.and.push.

the.suction.lock.up.

towards.the.suction.

cup..To.release.the.

suction.cup,.pull.the.

lock.back.towards.the.

support.arm.and.lift.the.

plastic.tab..

Important:.

be.ready.to.support.the.

device.when.it.releases.

from.the.windshield.
Connect.the.DC.power.cord.to.the.

11-15VDC.jack..

Then,.insert.the.cigarrette-lighter.plug.into.a.standard.

1-volt.outlet..The.device.automatically.turns.on.when.

you.connect.the.power.

4.

5.

Suction Lock

Release Tab

NOTE:.

Some.states.(including.California.and.Minnesota).

have.banned.the.use.of.windshield-mounted.devices.

inside.the.state’s.borders..It.is.your.responsibility.

to.understand.and.comply.with.all.the.laws.of.any.

state(s).in.which.you.operate.your.vehicle.
