How to get service or support
If you have a problem with the installation or operation of your Magicard
printer, then first please re-check to ensure that you have followed the
instructions given in this guide.
We also recommend that you visit
our website
www.magicard.com
where additional FAQs and technical
support information are available,
together with a “contact us” E-mail
form to report any problems.
If you still have a problem you will be
covered by our standard warranty
and may also be covered by our 3
year UltraCoverPlus extended
warranty and Loaner Service.
Follow the instructions under ‘Warranty’ to obtain assistance.
When Handling the Printer
Avoid touching the thermal printing edge of the thermal printhead.
Grease and contamination will shorten its life.
Before transporting the printer, remove the dye film cassette.
Pack the printer in its original packaging.
QuickStart Guide
Customers in North America, EU
and selected other countries enjoy
UltraCoverPlus 3 year extended
warranty, support and loaner program.
CONSUMABLES
Alto Consumables
PCF6 - 100 blank PVC cards in dispensers
plus 100 shot YMCKO dyefilm cassette.
PCF8 - 100 PVC Holopatch cards in
dispensers plus 100 shot YMCKO dyefilm
cassette.
PCF10 - 100 blank peel-and-stick cards in
dispensers plus 100 shot YMCKO dyefilm
cassette for use with prox cards, etc.
Alto M Consumables
PCF7 - 100 Hi Co magstripe cards in dispensers
plus 100 shot YMCKO dyefilm cassette (Alto M).
PCF9 - 100 Hi Co magstripe Holopatch cards in dispensers plus 100
shot YMCKO dyefilm cassette (Alto M).
We recommend that you use only Magicard consumables which have
been tested for color fidelity and consistency from batch to batch, and
are also guaranteed to safeguard your UltraCoverPlus warranty rights
(If applicable).
ABOUT THIS GUIDE
This guide is to assist you with the set-up and use of your Alto
printer.
The printer models covered by this document include:-
Alto Printer (Std.) M9005-724
Alto Printer (Mag.) M9005-725
The information contained in this guide is subject to change without
notice. Ultra Electronics Limited shall not be liable for errors
contained herein or for incidental or consequential damages in
connection with the furnishing, performance or use of this material.
This document contains proprietary information belonging to Ultra
Electronics Limited and may not wholly or partially be copied, stored
in a data retrieval system, disclosed to third parties or used for any
purpose other than that for which is was supplied, without the
express written authority of Ultra Electronics Limited. All rights are
reserved.
Magicard ® is registered as a trademark with the United States Patent
and Trademark Office, Reg. No. 2,197,276.
The HoloKote ® feature of Magicard ® printers is protected by US
PATENT No: 5,990,918 and by EUROPEAN PATENT SPECIFICATION
EP 0 817 726 B1.
Microsoft and Windows are trademarks of Microsoft Corporation.
Copyright 2007 Ultra Electronics Limited
CLEANING KITS
Alto and Alto/M
CK1 - Cleaning kit 5 T cards, 1 pen.
The Magicard T- C a rd cleaning system and pen is easy to use.
Regular cleaning is essential to keeping your printer in good shape.
WARRANTY
UltraCoverPlus Extended Warranty & Loaner Service
Ultra will • Replace without charge a failed printhead whatever the cause of failure
(provided Ultra consumables have been used exclusively).
• Repair without charge a failed printer
• Provide on request a loan unit to replace a printer returned for repair
• Pay for all shipments to the customer
You must • Keep this warranty information in a safe place
• Contact the service line indicated above if you have a problem
• Promptly ship to Ultra
- A failed printhead for replacement
- A failed printer for repair
- A loan printer when your unit is returned
- Pay for all shipments to Ultra
Making a Claim
a)
If your product is exhibiting a problem and is covered by UltraCoverPlus, FIRST contact our Tech Support
team for troubleshooting. The phone number is listed below.
b) If Tech Support cannot solve the problem and your product is defective, a Manufacturer’s Return
Authorization Number (MRAN) will be issued to you. Please have the product’s model and serial number ready
for warranty verification. (See label on rear of printer).
c) Once it has been verified that your product is covered by UltraCoverPlus, please ensure the consignment
address is forwarded before 1pm so that there is no delay in shipment of the loan printer if required.
d) On receipt of the loan unit, please ship the defective product to your Magicard Service Center promptly to
avoid rental charges for the loan unit. Retain all accessory items for use with the loan unit.
e) The product should be securely packed in its original packaging with a description of the problem and
quoting the MRAN number. Please also mark the MRAN number on the outside of the shipping carton.
f) If your defective unit is not received within two weeks of the loan machine being dispatched from Ultra, a
rental charge will apply.
g) Once your product has been repaired it will be shipped back to you. On receipt, please return the loan unit
promptly. After a period of two weeks, unless agreed in writing by Ultra, a rental charge will become payable.
h) Insurance and shipping costs incurred in sending the original product for service and returning the loan unit
are the responsibility of the customer. Ultra will pay freight costs to ship the loan unit out and to return the
repaired item.*If your printer is not covered by UltraCoverPlus, it may still be covered by our standard 12
month warranty.
Limited Warranty Information
1) Coverage: Ultra Electronics Ltd Warrants that the MAGICARD printer shipped with this Warranty statement will
conform to the manufacturers specifications and be free from defects in materials or workmanship for a period of 12
months from the date of original purchase by the user, but there are additional conditions on the printhead Warranty
(see paragraph 2).
2) Limited Printhead Warranty: Ultra warrants that, under normal use and service, thermal printheads will be free
from defects in material and workmanship for a period of twelve (12) months from the date of original purchase or
for a quantity of 10,000 printed cards, whichever comes first, provided that Ultra-approved card media is utilised.
If a Warranty claim is submitted for a defective printhead, Ultra will have the right to inspect the printhead and
samples of the printed and blank ID cards used with it for the purpose of verifying that the claimed defect has not
been caused by non-Ultra approved media, or by foreign particles or substances which have caused chemical or
physical damage. Ultra's decision in any such claims shall be final.
3) Warranty Claims: If the MAGICARD printer proves defective during this period, please contact the Ultra Service
Center, at the address and telephone/fax number given below. The Ultra Service Center personnel may first ask
you to carry out certain simple checks to confirm the nature of the problem, and if a return is appropriate they will
give you a Return Authorisation Number (MRAN) and consignment instructions to the appropriate repair center.
Ultra will, at its option, repair or replace the defective parts at no charge to the customer.
4) Warranty Limitations: The Warranty does not apply to MAGICARD printers that have been:
Damaged through physical or electrical mishandling.
Damaged through operation in environments which are outside normal office conditions in terms of corrosive
atmosphere, temperature, humidity, shock or vibration.
Improperly installed or interfaced to other products which may exhibit software problems or expose the
MAGICARD to improper voltages or control signals.
Used with consumables from any source other than Ultra Electronics.
Serviced or interfered with by anyone other than an Ultra Authorised Service provider.
5) Shipping: Insurance and shipping costs incurred in sending the MAGICARD printer for Warranty service are
the responsibility of the customer. Whenever possible Ultra Service Centers will use the same class of shipping
service selected and paid for by the customer to return the printer. Return shipping costs from Ultra to the
customer will be at Ultra's expense. After obtaining the MRAN as described above, the printer should be securely
packed in its original packaging with proof of date of purchase and a note describing the problem and quoting the
MRAN. The printer must be sent to the service center address supplied with the MRAN by the main service center.
This address may be different to the address listed below, but will generally be closer to you. Please also mark the
Return Authorisation Number on the outside of the shipping carton. All customs duties and taxes, if applicable, are
the responsibility of the customer.
6) Applicability: The Warranty and remedy provided above are exclusive and in lieu of all other warrants, either
express or implied, including but not limited to, implied warranties of merchantability and fitness for a particular
purpose. Any statements or representations made by any other person or firm are void. Neither Ultra Electronics
Ltd nor its affiliates shall be liable for any loss, inconvenience, or damage, including direct, special, incidental, or
consequential damages, resulting from the use or inability to use the Ultra product, whether resulting from breach
of Warranty or other legal theory even if Ultra has been advised of the possibility of such damage or loss.
This Warranty is governed by the laws of England. Any dispute arising out of or relating to this Warranty shall be
submitted for arbitration of this dispute or disputes pursuant to the rules and regulations of the UK Arbitration Act.
This Warranty gives you specific legal rights, and you may also have other legal rights which vary from country to
country so the above limitations and exclusions may not apply to all customers.
If you purchased your Alto printer in
North America or the EU and
selected other countries, then you
should be covered by our free three
year UltraCoverPlus extended
warranty and loaner program.
Outside of these territories our
standard one year limited warranty
applies (See below).
HOLOKOTE SECURITY
Ultra’s patented HoloKote anti-counterfeiting system is a built-in feature
of your Magicard printer and cannot be copied or bypassed. HoloKote
costs absolutely nothing to use and if you require a custom logo,
turnaround times and set up charges for custom keys are minimal.
HOLOPATCH CARDS
For even greater security, try HoloPatch ® cards. When you print with
HoloPatch cards, one of the HoloKote security logos is highlighted by a
highly reflective ‘super-diffuser’ patch, making the logo clearly visible at
a distance and under all lighting conditions.
Contact your dealer for supplies
APPROVALS
Federal Communications Commission (FCC) Statement
This equipment has been tested and found to comply with the limits
for a Class A digital device, pursuant to part 15 of the FCC rules.
These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference in which case the
user will be required to correct the interference at his own expense.
Canadian Department of Communications Statement
This digital apparatus does not exceed the Class A limits for radio
noise emissions from digital apparatus set out in the Radio
Interference Regulations of the Canadian Department of
Communications. Le présent appareil numérique n'émet pas de bruits
radioélectriques dépassant les limites applicable aux appareils
numériques de la class A prescrites dans le Règlement sur le
brouillage radioélectrique édicté par le ministère des Communications
du Canada.
EU Declaration of Conformity
The EU Directives covered by this Declaration
89/336/EEC
Electromagnetic Compatibility Directive, amended by
92/31/EEC & 93/68/EEC
72/23/EEC Low Voltage Equipment Directive, amended by
93/68/EEC
The Product Covered by this Declaration
Magicard Alto Card Printer
The Basis on which Conformity is being Declared
The product identified above complies with the requirements of the
above EU Directives by meeting the following standards
BS EN 50 081-1 EMC Generic Emission Standard Part 1
BS EN 50 082-1 EMC Generic Emission Standard Part 1
BS EN 60 950 : 1992 Safety of Information Technology Equipment
including Electrical Business Equipment
CALL US (425) 556 9708
Ultra Electronics Inc.
MAGICARD US Service Center
6711 - 176th Avenue NE
Redmond, WA 98052, USA
Fax: (425) 556 3962
CALL EU +44 (0)1305 762 115
Ultra Electronics Limited
MAGICARD Service Centre
Waverley House, Hampshire Road, Granby Estate
Weymouth, Dorset, DT4 9XD, UK
Fax: +44 (0) 1305 777 904
standard standard option option Alto/M
If you have warranty enquiries
or experience a problem, visit
our website
www.magicard.com
for support
or call our service center.
