PARTS LIST FOR MODELS 546 & 549
Ref.
No.
Part No.
Part Description
1.
747-1161A
Control Handle
2.
749-1092A
Upper Handle
3.
747-04080
Grass Bag Frame
4.
749-0928A
Lower Handle
5.
720-0279
Wing Nut
6.
710-1205
Rope Guide
7.
710-1174
Carriage Bolt 5/16-18 x 2”
8.
664-04011
Grass Bag
9.
720-0284
Wing Nut
10.
746-1130
Control Cable 40”
11.
726-0240
Cable Ties
12.
714-0104
Hairpin Clip
13.
732-04090A
Torsion Spring — RH
14.
732-04089A
Torsion Spring — LH
15.
731-04134A
Grass Bag Door
16.
732-1014
Torsion Spring
17.
747-0710
Hinge Pin
18.
732-0700
Wire Rod
19.
731-04998
Trail shield
20.
748-0377C
Blade Adapter
21.
710-1257
Hex Cap Screw 3/8-24 x 2.5
22.
736-0524B
Blade Bell Support
23.
17032A
Chute Deflector Adapter
24.
742-0741
21” Mulching Blade
25.
712-0431
Flange Lock Nut 3/8-16
26.
15261C
Height Adjustment Plate
27.
687-02077
Pivot Arm Assembly — RH
687-02076
Pivot Arm Assembly — LH
28.
732-0404
Spring Lever
29.
738-0507B
Shoulder Screw
30.
731-04204
Deluxe Bail Cover
31.
720-0426
Spring Lever Knob
32.
710-0216
Hex Screw 3/8-16 x 0.75
33.
687-02074
Front Height Adjuster Assembly — RH
687-02075
Front Height Adjuster Assembly — LH
34.
687-02039
Pivot Arm Assembly — RH
687-02040
Pivot Arm Assembly — LH
35.
782-5002B
Front Baffle
36.
710-0654A
Hex Washer Screw 3/8-16 x 1.0
37.
731-04150
Rear Baffle 21” Rd.
38.
710-0286
Machined Screw 1/4-20
39.
710-1652
TT Screw 1/4-14 x .625
40.
710-04371
Hex Screw1/4-15
41.
712-04064
Flange Lock Nut 1/4-20
42.
787-01231
Deck 21”
43.
734-04014
Front Wheel 8x2.125 Gray IDL
44.
736-0270
Bell Washer.265 ID x.75 OD
45.
687-02055
Mulching Plug
46.
731-04177
Side Discharge Deflector
47.
710-0599
Screw 1/4-20 x.500
48.
710-0514
Hex Cap Screw 3/8-16 x 1.0
49.
736-0451
Shoulder Washer.320 ID x.930 OD
50.
710-0703
Hex Carriage Screw 1/4-20
51.
712-0397
Wing Nut
52.
750-04162
Spacer.375 O.D. x.50 I.D. x 1.02”
53.
747-0996
Chute Door Pivot Rod
54.
734-04127
Rear Wheel 12x2.125 Gray IDL
55.
687-02056
Handle Bracket Assembly — RH
687-02057
Handle Bracket Assembly — LH
56.
687-02033
Handle Bracket — RH
687-02031
Handle Bracket — LH
57.
732-0866
Spring Lever
58.
720-0312
Spring Lever Grip
59.
736-0182
Spring Washer.500 x 1.00 x.022
60.
736-0504
Wave Washer.510 x.750 x.017
