A FEW PRECAUTIONS:
• Never listen to loud music for
prolonged periods. Please
see the Safety Instructions
on page 2 for information on
hearing protection.
• Never plug amplifi er speaker-level outputs into
anything except speakers.
• Never use guitar cables to connect amplifi ers to
speakers.
• Before making connections to an external
amplifi er, or reconfi guring an amp’s routing, turn
the amp’s level (gain) controls down, turn the
power off , make the changes, turn the power back
on, and then turn the level controls back up.
• When you shut down your equipment, turn off any
external amplifi ers fi rst. When powering up, turn
on the amplifi ers last.
• Save the shipping box and packing material! The
box can also be turned into a unique hat, lunch
box, or handbag to accessorize your mixer.
