CMS601 DC
Tannoy adopts a policy of continuous improvement and product specification is subject to change
CMS601 DC data file // issue 1.06 // 10.01.08
TECHNICAL SPECIFICATIONS
Frequency Response (-3dB) (1) 75Hz - 30kHz
BM Back can
Frequency Range (-10dB)
(1) 50Hz - 30kHz
BM Back can
Frequency Range (-10dB)
(1) 46Hz - 30kHz
PI Back can
System Sensitivity (1W @1m)
(2) 91dB (1W = 2.83V for 8 Ohms)
Nominal Coverage Angle 90 degrees conical
Coverage Angle (1kHz to 6kHz) 111 degrees conical
Directivity Factor (Q)
4.7 averaged 1kHz to 6kHz
Directivity Index (DI) 6.5 averaged 1kHz to 6kHz
Rated Maximum SPL (2)
Average 110dB
Peak 116dB
Power Handling
Average 80W
Programme 160W
Peak 320W
Recommended Amplifier Power 160W @ 8 Ohms
Nominal Impedance
8 Ohms
Transformer Taps (via front rotary switch)
70V 60W / 30W / 15W / 7.5W / OFF &
low impedance operation
100V 60W / 30W / 15W / OFF &
low impedance operation
Distortion
10% Full Power 2nd Harmonic 3rd Harmonic
250Hz 1% 0.32%
1kHz 0.18% 0.32%
10kHz 1% 0.18%
1% Full Power 2nd Harmonic 3rd Harmonic
250Hz 0.25% 0.25%
1kHz 0.06% 0.18%
10kHz 0.45% 0.14%
Crossover 2kHz - 2nd order LF, 3rd order HF
(with dynamic HF protection)
(1) Average over stated bandwidth. Measured at 1 metre on axis.
(2) Unweighted pink noise input, measured at 1 metre in an anechoic chamber
(3) Long term power handling capacity as defined in EIA - 426B test
A full range of measurements, performance data, CLF and Ease™ Data can be
downloaded from www.tannoy.com
Full independent verification of published specifications carried out by NWAA Labs,
California can also be obtained from the downloads section of www.tannoy.com
Tannoy operates a policy of continuous research and development. The introduction
of new materials or manufacturing methods will always equal or exceed the
published specifications, which Tannoy reserves the right to alter without prior
notice. Please verify the latest specifications when dealing with critical applications.
System CMS601 DC
Transducers
8001 4530 CMS601 DC BM White / paintable 2
8001 4540 CMS601 DC PI White / paintable 2
8001 4181 CMS601 DC Plaster (Mud) Ring Zinc plated steel 10
8001 4590 CMS601 DC PI 8ohm back can Zinc plated steel 1
7600 1658 CMS601 DC 60W transformer kit 8 ohm N/A 1
PART NUMBER PACKED QUANTITY BAFFLE / GRILLE COLOUR MODEL NAME
Ordering Information
Low Frequency 1 x 165mm (6.50") Dual Concentric™
constant directivity point source driver with
multi fibre paper pulp cone
High Frequency 1 x 25mm (1.00") titanium dome with
neodymium magnet system
Physical
Enclosure
Back can Zinc plated steel
Baffle Reflex loaded UL 94V-0 rated ABS
Grille Steel, with weather resistant coating
Safety Features Safety ring located at rear of enclosure
for load bearing safety bond
Clamping Design Security toggle clamp
Min / Max Clamping Range 0.0mm (0.0") / 20.0mm (0.79")
Recommended Clamp Torque 1.5Nm
Back Can Options
Blind Mount (BM) Complete with fixed back can
Pre Install (PI) Separate back can for pre installation
Cable Entry Options Cable clamp and squeeze connector for
conduit up to 22mm
Conduit Knockouts 3 Sets of horizontal positions
19 / 22 / 28mm (0.75" / 0.87" / 1.10")
Connectors Removable locking connector with screw
terminals with "loop through" facility
Safety Agency Ratings
(pending)
UL-1480, UL-2043, CE
BM Hole Cutout Diameter 253mm (9.96")
PI Hole Cutout Diameter 253mm (9.96")
Dimensions
Bezel diameter 280mm (11.02")
Front of ceiling to
rear of back can (BM) 258mm (10.16")
Front of ceiling to
top of safety loop (BM) 275.5mm (10.84")
Front of ceiling surface to
rear of speaker unit (PI) 99.40mm (3.91")
Front of accessory back can
bezel to top of safety loop (PI) 168.50mm (6.60")
Net Weight (ea)
CMS601 DC BM 7.45kg (16.42lbs)
CMS601 DC PI 4.09kg (9.02lbs)
CMS601 DC PI back can 3.685kg (8.12lbs)
Included Accessories C Ring, tile bridge, paint mask,
cutout template, grille
Optional Accessories Plaster (Mud) Ring
