6 • 461230404
2
Caster
wrench
Locking casters
on front legs.
Attach
, non-locking
casters to rear legs. Tighten casters using the
caster wrench provided.
locking casters to front legs
ASSEMBLY – Model No. 461230404
1
Rear view
Door brace
First
4.2X10mm
, remove door brace from rear legs. Place door
brace onto front legs as shown. Tabs on brace fit
inside legs. Secure brace to back of front legs using
one
self-tap screw
on each side.
(WW)
Left front leg
Rear view
WW
NOTE: Some grills parts shown in the assembly steps may differ slightly in appearance from
those on your particular grill model. However, the method of assembly remains the same.
