TECHNICAL SPECIFICATIONS
PHYSICAL
Size
- Reader Enclosure
(max. including Wiegand Head)
240 x 100 x 100mm (9” x 4” x 2”)
- Base Enclosure 210 x 100 x 100mm (8” x 4” x 4.33”)
Weight Reader less than 1 kg (2.2lbs)
Base Station less than 400g (1lb)
Housing ABS Plastic Case
Colour Light Grey
Power
- Voltage
9 – 15Vdc
- Current
Consumption
140mA (passive), 250mA (peak)
Power
- Reader Power
Charging Current Consumption: 1.1A
Active Consumption: 60mA
Power Save Mode: Minimal
- Base Station When charging batteries:
1.4A, 10Vdc
- Charge Time 30 to 50 minutes, overcharge
protected
- Fully charged Usage 9-20 hours depending on
read head
- Battery Type 1.2V NiMH rechargeable batteries
- Battery Charging Pins User Replaceable
LCD Display 4 line by 16 character display with
backlight
Keypad 21 key membrane keypad.
FUNCTIONALITY
Memory 2MB
Database
- Cardholders
Storage of up to 130,000
cardholders on the handheld reader.
- Transactions Up to 2,000 transactions in offline
operation.
Read Head Specification
- Card Motion
Manual swipe/Insert/Presentation
(depending on head used)
- Available Head All Wiegand encoded cards
Technologies Magnetic stripe IS02
Barcode using external reader
Proximity
Smart Card
Configuration Operational parameters are
downloaded from host controller via
the base station. Some
configuration setting can also be
set using the keypad.
COmmUNICATION INTErFACE
Base Station Communications Bi-directional optical link between
reader and base station
PrOdUCT COdES
RDR/032/201 S3010 Portable Reader (MiFare)
RDR/032/101 S3010 Portable Reader (Prox)
RDR/039/100 S3010 Portable Reader Base
CEM Systems Ltd Unit 4 Ravenhill Business Park Ravenhill Road Belfast BT6 8AW Northern Ireland
Tel: +44 (0)28 9045 6767 Fax: +44 (0)28 9045 4535 email: [email protected]
www.cemsys.com
Base Station
The S3010 base station provides a two-way communication
interface between the reader and the AC2000 central
computer or the webEntry controller. This allows card IDs
to be loaded from the central computer or the webEntry
controller to the reader database and stored transactions to
be transferred back to the central computer. The database
will expire after 24 hours, which means that the reader must
be returned to the base station to ensure that data is kept
current. The base station also provides battery management
circuitry.
Battery management
Four user replaceable rechargeable NiMH cells are held in an
external compartment. These provide operational power for up
to twenty hours of continuous use.
In order to extend battery life, the reader will enter
Powersave Mode after a period of inactivity. The time delay
from the last operation and shut down is user configurable,
between 1 and 99 minutes. The reader can be re-activated by
simply pressing the “Start” button on the keypad. When the
reader is plugged into the base station, the batteries are “fast
charged” if necessary under both temperature and voltage
control.
PRoDUCT HIgHLIgHTS
CEM/B/012 Rev I
Product specifications and availability is subject to change without notice. Certain product names mentioned herein may be trade names
and/or registered trademarks of their companies.
