Connecting the TV set and surround speakers to the decoder:
For important information regarding loudspeaker
configurations and modes of operation please refer to
the chapter 'Loudspeaker configurations for the
DD 1535 R'.
The components of your system should be connected as
shown in Wiring Diagram 1. This is the procedure:
• Connect the surround loudspeakers to the
appropriate output terminals on the decoder.
• If present, connect the input of the active sub-woofer
to SUB OUT.
• Connect the monitor socket on the decoder to your
TV set using a video cable.
Note:
If your TV set has a SCART input socket, please use
the S-Video / SCART adaptor lead supplied.
• Connect the aerial input FM ANT to a FM aerial
socket.
To check the connection between your TV set and the
DD 1535 R
switch your television to the external AV input
and temporarily call up the 'Configuration menu'.
This is done by holding the     button on the front
panel of the DD 1535 R or the F6 pressed in.
• This is done by holding the     button on the
front panel of the DD 1535 R pressed in.
If this menu does not appear, the screen shows
monochrome picture or the picture is unstable, please
read the section 'Trouble-shooting'.
