Tripp Lite PDU1230 User Manual

Model #: pdu1230

background image

Tripp Lite

1111 West 35th Street

Chicago, IL 60609 USA

Telephone: +(773) 869 1234

E-mail:

[email protected]

Model #: PDU1230

Single-Phase Basic PDU, 30A 208/240V, 1U Horizontal Rackmount, 4 C19 and 16 C13 outlets, NEMA L6-30P
input plug

Highlights

Basic single phase 30A 208/240V PDU

1U horizontal rackmount installation

NEMA L6-30P input; 15 ft. / 4.5m line cord

20 outlets (4 C19, 4 C13 front / 12 C13 rear)

Reversible housing; 5.2 in. / 13.2 cm depth

Description

Tripp Lite Basic Power Distribution Units / PDU systems offer reliable rackmount power distribution. Supplies equipment with continuous power from
any protected UPS, generator or mains input power source. High quality design includes rugged all-metal housing and secure rackmount installation
with included mounting accessories.

Applications

Multi-outlet power distribution unit is the ideal means of powering multiple loads in 19-inch rackmount, wallmount and under-counter

applications, such as internetworking, PC systems, telecommunications, audio/video, security, sound reinforcement and more. Ideal for

distribution of UPS, generator or commercially derived AC power to protected equipment.

Package Includes

PDU1230 Power Strip

Warranty information

Instruction manual

Features

30A single phase 208/240V Basic Power Distribution Unit / PDU (agency de-rated to 24A continuous)

Attached NEMA L6-30P 30A 208/240V input plug with 15 ft. / 4.5m line cord

1U horizontal rackmount format installs in one rack space

20 outlets (4 C19, 4 C13 front / 12 C13 rear)

Mounting flanges support installation in 2 and 4 post racks, with additional support for wall-mount and under-counter installation formats

Back panel grounding lug

Specifications

OVERVIEW

PDU Type

Basic

OUTPUT

Frequency compatibility

50 / 60 Hz
