General Data
50 and 60 Hz SI Units and (English Units)
High Effi ciency Shells - 0.75 inch (19 mm) Internally Enhanced Cu Tube:
Condenser:
Nominal Shell
500
500
500
700
700
700
1000
1000
1000
1000
Bundle Size
Small
Medium
Large
Small
Medium
Large
Small
Medium
Large
Extra Large
Number of Passes
2
2
2
2
2
2
2
2
2
2
Min Flow L/s (gpm)
31 (487)
34 (542)
37 (586)
42 (668)
47 (744)
52 (816)
59 (938)
67 (1056)
74 (1176)
77 (1213)
Max Flow L/s (gpm) 113 (1786) 125 (1987) 136 (2148) 155 (2450) 172 (2727) 189 (2993) 217 (3441) 244 (3874) 272 (4311) 280 (4447)
Evaporator:
Nominal Shell
500
500
500
700
700
700
1000
1000
1000
1000
Bundle Size
Small
Medium
Large
Small
Medium
Large
Small
Medium
Large
Extra Large
Number of Passes
2
2
2
2
2
2
2
2
2
2
Min Flow L/s (gpm)
26 (407)
29 (458)
32 (511)
36 (566)
40 (628)
44 (698)
52 (822)
58 (921)
64 (1021)
72 (1136)
Max Flow L/s (gpm) 94 (1493) 106 (1680) 118 (1873) 131 (2077) 145 (2304) 161 (2559) 190 (3013) 213 (3377) 236 (3745) 263 (4165)
Evaporator:
Nominal Shell
500
500
500
700
700
700
1000
1000
1000
1000
Bundle Size
Small
Medium
Large
Small
Medium
Large
Small
Medium
Large
Extra Large
Number of Passes
3
3
3
3
3
3
3
3
3
3
Min Flow L/s (gpm)
17 (271)
19 (305)
21 (340)
24 (378)
26 (419)
29 (465)
35 (548)
39 (614)
43 (681)
48 (757)
Max Flow L/s (gpm)
63 (995)
71 (1120)
79 (1248)
87 (1385)
97 (1536) 108 (1706) 127 (2009) 142 (2251) 158 (2497) 175 (2777)
Standard Effi ciency Shells - 1.00 inch (25.4 mm) Int. Enhanced Cu Tube:
Condenser:
Nominal Shell
500
500
500
700
700
700
1000
1000
1000
1000
Bundle Size
Small
Medium
Large
Small
Medium
Large
Small
Medium
Large
Extra Large
Number of Passes
2
2
2
2
2
2
2
2
2
2
Min Flow L/s (gpm)
31 (499)
35 (557)
38 (606)
43 (682)
48 (764)
53 (838)
58 (925)
64 (1020)
75 (1172)
83 (1307)
Max Flow L/s (gpm) 115 (1831) 129 (2041) 140 (2221) 158 (2501) 177 (2801) 194 (3071) 214 (3391) 236 (3741) 276 (4372) 302 (4792)
Evaporator:
Nominal Shell
500
500
500
700
700
700
1000
1000
1000
1000
Bundle Size
Small
Medium
Large
Small
Medium
Large
Small
Medium
Large
Extra Large
Number of Passes
2
2
2
2
2
2
2
2
2
2
Min Flow L/s (gpm)
28 (447)
31 (496)
35 (550)
39 (625)
45 (706)
49 (784)
49 (781)
236 (3741) 63 (1003)
70 (1115)
Max Flow L/s (gpm) 103 (1638) 115 (1818) 127 (2018) 145 (2293) 181 (2874) 181 (2874) 181 (2864) 207 (3287) 232 (3678) 258 (4090)
Evaporator:
Nominal Shell
500
500
500
700
700
700
1000
1000
1000
1000
Bundle Size
Small
Medium
Large
Small
Medium
Large
Small
Medium
Large
Extra Large
Number of Passes
3
3
3
3
3
3
3
3
3
3
Min Flow L/s (gpm)
19 (298)
21 (330)
23 (367)
26 (417)
30 (471)
33 (523)
33 ((521)
38 (598)
42 (669)
47 (744)
Max Flow L/s (gpm) 69 (1092)
76 (1212)
85 (1346)
96 (1529) 109 (1726) 121 (1916) 120 (1909) 138 (2191) 15 (2452)
172 (2726)
Table GD-3 –Evaporator and Condenser Flow Rates (Minimum and Maximum, liters per second, gallons per minute)
