Page 6
6
O
ther connections
5.1 CH SURROUND
FRONT
REAR
CENTER WOOFER
L
R
COMPONENT
VIDEO OUT
PROGRESSIVE
SCAN
Y
Pb
Pr
AUDIO
OUT
S-VIDEO
OUT
VIDEO
OUT
VIDEO
OUTPUT
R
L
DIGITAL
OUT
DIGITAL
OUT
COAXIAL
EXTERNAL
INPUT
TO TV
S-VIDEO
SCART
COMPONENT/
PROGRESSIVE
SCAN
OPTICAL
2
7
1
6
5
8
3
4
1
Digital Audio Out sockets
(optical or coaxial)
to amplifier or TV.
2
SCART/PÉRITÉLÉVISION output
(
1
)
: RGB
output to AV amplifier or TV if button 3 is set to
SCART
or on CVBS if button 3 is set to another
position.
3
VIDEO OUTPUT
is used to select the type of
output signal:
SCART
for the
TV
connection
(Scart/Peritel) (
2
),
COMPONENT
for
COMPONENT VIDEO OUT
connections (
6
), or
S-VIDEO
for the
S-VIDEO OUT
connection (
4
).
4
S-VIDEO Out sockets (Ushiden signals Y/C)
:
to AV amplifier or TV.
5
Digital audio output
vto channels 5.1 amplifier.
6
Progressive Scan output (Y, P
B
, P
R
)
: to TV or
devices equipped with equivalent inputs with
button 3 on
COMPONENT VIDEO OUT
.
7
Composite Video Out sockets (CVBS)
: to AV
amplifier or TV (standard-quality picture).
8
Analogue Audio Out
sockets to stereo
amplifier.
Video connections (picture)
The connection setup shown on page 5 provides a rapid connection of your player. This setup
gives standard-quality sound reproduction and an optimum-quality picture (RGB). You may
need to use other connection setups suited to the connectors available on your other devices or
to get maximum performance out of your player. Your player has other sockets for these
purposes.
Picture quality
Type of connector used
***
• TV socket (2) (SCART socket – RGB signals)
***
• Components sockets Y, Pb, Pr (6) (RCA sockets - signals Y, P
B
, P
R
)
**
• S-VIDEO OUT socket (4) (Hosiden socket- Y/C signal)
*
• VIDEO OUT sockets (7) (RCA sockets- CVBS signal)
If the connecting cables are not supplied with
your player, get good-quality cables, preferably
well-known brands.
Connection through the scart socket supplies
both video and audio signals. If you choose the
connection using a scart cable, you don’t need to
connect any other sockets. Make sure that button
3 at the back is positioned on SCART and that
your TV set supports that type of signal.
1.
1.
Connections
The table below lists the connectors and quality of your player’s output signals. Select one of the 4
connection setups shown for video connection and one of the 3 connection setups shown for audio
connection.
