Installation —Q Fan
QFNA-IOM-1 11
Table 2 - Unit Weight (Less Motor, Drive, Accessories and Shipping Package)
Arrangement 9 Arrangement 1
Unit Size Class I Class II Class I Class II Class III
16
19
125
165
135
180
*NA
NA
*NA
NA
155
200
21
24
190
220
210
255
NA
NA
NA
NA
230
285
27
30
260
325
300
375
NA
NA
315
385
335
415
33
36
410
525
465
600
425
545
480
615
515
655
40
44
690
920
775
1010
705
920
790
1025
830
1070
49
54
1020
1090
1075
1140
NA
NA
NA
NA
NA
NA
60 1730 1830 NA NA NA
Note: *NA - This combination of arrangement, class and size is not available.
Figure 2—Integral Base for Arrangement 1
Top View
