TANDBERG Maestro MXP
246
Signal name
CON.
3 Pin
CON.
1 Pin
CON.
5 Pin
CON.
2 Pin
CON.
4 Pin
Cable color
DDC Clock
6
15
Orange
DDC Data
7
12
White
Vertical Sync
8
14
Yellow
DDC Power
(+5V)
14, 16
9
Red
Digital return
15
5, 10
Black
RGB Red
C1
1
Red Coax
RGB Green
C2
2
Green Coax
RGB Blue
C3
3
Blue Coax
Horizontal Sync
C4
13
Brown
RGB Return
C5
6, 7, 8
RGB Coax Shield
Outer Shield
Ground
Shell
Shell
Outer Shield
Audio Left
Centre
Tip
Audio Black
Audio Right
Ring
Centre
Audio Red
Audio GND
Gnd
Sleeve
Gnd
Audio Shield
PC cable, VGA - DVI with integrated audio
* Applies to T3000 MXP with new hardware
