6 Trouble-shooting guide
7 Technical data
8
110903
Problem Possible cause
No picture, no sound > Mains switch or receiver and/or transmitter
not switched on
> Cable connections faulty
> Receiver and transmitter set to different
channels
Interference in transmission of
picture and sound > Antennae of the system not aligned optimal-
ly
> Interference on the channel selected. Reme-
dy: select different transmission channel.
> Proximity to a microwave oven that is in
operation, causing interference.
> Distance between transmitter and receiver
too great.
Transmission of remote control
signals not working > Faulty cable connection
> No line of sight between IR remote control
and receiver, resp. between IR transmitter
and signal source.
Transmission interrupted periodi-
cally > Several receiver channels set, this leads to
an automatic alternation between receiving
channels.
Transmitter
Output level 10 dBm
Transm. frequency
Modulation 2,4 bis 2,4835 GHz
FM (Video u. Audio)
Level Video in
Audio in
1Vss
1Vss
Impedance Video in
Audio in
75 Ohm
600 Ohm
Power supply
Dimensions
Weight 9V DC 90mA
102 x 41 x 115mm
130g
Receiver
Video level
Audio level 1Vss
1Vss
Sensitivity -85 dBm
Transmission fre-
quency of remote
control signals 434 MHz
IPower supply
Dimensions
Weight 9V DC 90mA
102 x 41 x 115mm
130g
