4.4 Bill of Materials
www.ti.com Board Layout, Bill of Material, and Schematics
Table 7. Bill of Materials for TAS5704EVM
Description RefDes QTY MFR MFR:Part No. Vendor Vendor Part No. ALT Part No.
TI-SEMICONDUCTORS
Modulator/HBRIDGE U1 1 Texas Instruments TAS5704PAP Texas TAS5704PAP No ALT Part No.
TQFP64-PAP Instruments
Single Inverter Gate, SOT23-DBV5 INV1, INV2 2 Texas Instruments SN74AHC1GU04DBVR Digi-Key 296-1095-2 296-1095-1
Single 2 to 1 MUX W/Common Strobe, MUX 1 Texas Instruments SN74LVC2G157DCTR Digi-Key 296-13266-2 296-13266-1
TSSOP8-DCT
Processor Supervisor Circuit, 3.3V U3 1 Texas Instruments TPS3825-33DBVT Digi-Key 296-2636-2 296-2636-1
Voltage Regulator, LDO Fast Trans. VR1 1 Texas Instruments TPS76733QD Digi-Key 296-2738-5 No ALT Part No.
3.3Vdc 1.0A, SOP8-D
S-Ended ANA-IN 24BIT 96kHz Stereo ADC 1 Texas Instruments PCM1808PW Digi-Key 296-19773 No ALT Part No.
ADC, TSSOP14-PW
Digital Audio interface receiver U2 1 TI - Burr Brown DIR9001PW Digi-Key 296-21389-5 No ALT Part No.
TSSOP28-PW
SEMICONDUCTORS
Optical receiver, 3.3V, PCB-RA ROHS OPTO 1 Toshiba TORX147LFT Digi-Key TORX147LFT TORX141
Crystal, 12.288MHz, HC49US Y1 1 ECS ECS-122.8-S-4 Digi-Key X174 No ALT Part No.
Transistor NPN 50V PreBiased/4.7K Q3 1 Diodes Inc. DDTC143TCA-7 Digi-Key DDTC143TCADITR DDTC143TCADICT
100mA SOT23-DBV3
Transistor PNP 50V PreBiased/4.7K Q1, Q2, Q4–Q6 5 Diodes Inc. DDTA143TCA-7 Digi-Key DDTA143TCADITR DDTA143TCADICT
100mA SOT23-DBV3
LED, Green 2.0V SMD0805 LED1, LED2, 5 Lumex Optical SML-LXT0805GW-TR Digi-Key 67-1553-2 67-1553-1
LED4, LED5,
LED7
LED, Red 2.0V SMD0805 LED9 1 Lumex Optical SML-LXT0805IW-TR Digi-Key 67-1552-2 67-1552-1
LED, Yellow 2.0V SMD0805 LED6, LED8, 3 Lumex Optical SML-LXT0805YW-TR Digi-Key 67-1554-2 67-1554-1
LED10
LED, Blue SM1206 LED3 1 Avago HSMR-C150 Digi-Key 516-1436-2 516-1436-1
Technologies
CAPACITORS
CAP 33pF 50V CERM 0603 NPO C64, C65 2 Panasonic ECJ-1VC1H330J Digi-Key PCC330ACVTR PCC330ACVCT
CAP 4700pF 50V CERM 0603 X7R C42, C43, C61 3 Panasonic ECJ-1VB1H472K Digi-Key PCC1780TR PCC1780CT
CAP 0.01 µ F 16V CERM 0603 X7R C78, C91 2 Murata Electronics GRM188R71C103KA01D Digi-Key 490-1525-2 490-1525-1
CAP 0.01 µ F 50V CERM 0603 X7R C7 1 Panasonic ECU-V1H103KBV Digi-Key PCC103BVTR PCC103BVCT
CAP 0.047 µ F 16V CERM 0603 X7R C10, C41, C88, 4 Panasonic ECJ-1VB1C473K Digi-Key PCC1758TR PCC1758CT
C89
CAP 0.068 µ F 16V CERM 0603 X7R C63 1 Panasonic ECJ-1VB1C683K Digi-Key PCC1760TR PCC1760CT
CAP 0.1 µ F 16V CERM 0603 X7R C5, C8, C11, 17 Panasonic ECJ-1VB1C104K DIGI-KEY PCC1762TR PCC1762CT
C25, C55,
C66–C68, C70,
C71, C73,
C80–C83, C90,
C93
CAP 0.1 µ F 50V CERM 0603 X7R C9, C47 2 Murata GRM188R71H104KA93D Digi-Key 490-1519-2 490-1519-1
CAP 0.22 µ F 25V CERM 0603 X7R C1, C16, C23, 4 Murata Electronics GRM188R71E224KA88D Digi-Key 490-3290-2 490-3290-1
C26
CAP 1.0 µ F 25V CERM 0603 X5R C2, C18, C24 3 Panasonic ECJ-1VB1E105K Digi-Key PCC2422TR PCC2422CT
CAP 4.7 µ F 6.3V CERM 0603 X5R C13 1 TDK Corp. C1608X5R0J475M Digi-Key 445-1417-2 445-1417-1
CAP 0.1 µ F50V CERM 0805 X7R C15, C29, C35, 4 Panasonic ECJ-2YB1H104K Digi-Key PCC1840TR PCC1840CT
C44
CAP 1.0 µ F 50V CERM 0805 Y5V 0 Taiyo Yuden UMK212F105ZG-T Digi-Key 587-1308-2 587-1308-1
CAP 1.0 µ F 50V METAL Polyester film C48–C50, C79 4 EPCOS B32529C5105J Digi-Key 495-1087 B32529C105J
MKT
CAP 1 µ F 50V RAD ALUM ELEC FC C86, C87 2 Panasonic EEU-FC1H1R0 Digi-Key P10312 No ALT Part No.
CAP 10 µ F 16V RAD ALUM ELEC KGA C46, C53, C54, 11 Panasonic ECE-A1CKG100 Digi-Key P910 No ALT Part No.
C57, C69, C72,
C74, C76, C84,
C85, C92
CAP 15 µ F 50V RAD ALUM ELEC FC C37 1 Panasonic EEU-FC1H150 Digi-Key P10317 No ALT Part No.
CAP 22 µ F 10V RAD ALUM ELEC KGA C6, C60 2 Panasonic ECE-A1AKG220 Digi-Key P905 No ALT Part No.
CAP 47 µ F 16V RAD ALUM ELEC FC C4 1 Panasonic EEU-FC1C470 Digi-Key P11196 No ALT Part No.
CAP 220 µ F 50V RAD ALUM ELEC FC C3, C28, C36, 4 Panasonic EEU-FC1H221 Digi-Key P10325 No ALT Part No.
C38
CAP 470 µ F 50V RAD ALUM ELEC FC C58, C59 2 Panasonic EEU-FC1H471L Digi-Key P11260 No ALT Part No.
