640 & 650 Series Handle, Tine Shields & Tines
Ref.
Part Number
Description
1.
649-04066
Upper Handle Assembly
2.
710-0599
Screw, 1⁄4-20 x .500
3.
710-3008
Hex Screw, 5⁄16-18 x .75
4.
710-3180
Hex Screw, 5⁄16-18 x 1.75
5.
712-04063
Flange Lock Nut, 5⁄16-18
6.
746-04413
Forward Cable
7.
747-04789
Clutch Bail
8.
749-04208
Lower Handle Assembly
9.
786-04188
Handle Support Bracket
10.
786-04200
Handle Panel
11.
686-04098
Reverse Handle Assembly
12.
720-0270A
Reverse Handle Grip
13.
726-0135
Speed Nut, .3125
14.
746-04414
Reverse Cable
15.
686-04077
Tine Shield, 17” (B, C)
—
686-04073
Tine Shield, 15” (A)
16.
710-0597
Hex Screw, 1⁄4-20 x 1.00
17.
710-3008
Hex Screw, 5⁄16-18 x .75
18.
712-04063
Flange Lock Nut, 5⁄16-18
19.
712-04064
Flange Lock Nut, 1⁄4-20
Ref.
Part Number
Description
20.
712-04065
Flange Lock Nut, 3⁄8-16
21.
715-0108
Spring Pin, 1⁄4 x 1.00
22.
732-04320
Torsion Spring
23.
738-04320
Shoulder Screw, 5⁄16-18 x .405 x .435
24.
738-0533
Shoulder Screw, .498 x 1.635
25.
750-04556
Split Spacer, .350 x .268 x .375
26.
786-04092
Reverse Stop Arm
27.
786-04098
Support Bracket
28.
786-04104
Depth Drag Bar
29.
786-04292
Adjustable Depth Bar
30.
786-04363
Tail Bracket, Left
31.
786-04364
Tail Bracket, Right
32.
710-0347
Hex Screw, 3⁄8-16 x 1.75
33.
712-04065
Flange Lock Nut, 3⁄8-16
34.
742-04227
Bolo Tine, 10” LH
35.
742-04226
Bolo Tine, 10” RH
36.
710-0514
Hex Screw, 3⁄8-16 x 1
37.
712-3000
Hex Lock Nut, 3⁄8-16
38.
686-04065
Tine Holder (A)
—
686-04066
Tine Holder (B, C)
A — Bronco
B — Super Bronco
C — Pro Line
