FIBRE PRODUCTS
Siemon provides a complete line of MT-RJ Small Form Factor (SFF) interconnect
products — providing the utmost in versatility and performance. Siemon MT-RJ
connectors pack all the benefits of duplex fibre optic performance in a compact “RJ”
style design. Two key features have been incorporated into Siemon’s MT-RJ system.
The first is the hinged adapter latch which allows for easy corrections of polarity
errors. The second feature is the lead-in tube of both the 62.5 and 50 micron
connectors which utilizes a dual entrance tube to facilitate easier routing of fibres
into the connector.
No one offers a wider variety of MT-RJ solutions for the work area or the
telecommunications room. Siemon MT-RJ work area adapter products are
compatible with our current line of MAX
® and CT ® products, MX-SM ® Boxes, and
Fibre Outlet Boxes (FOB2), providing a range of solutions as well as the ability to
mix copper and fibre in a single faceplate or service box. In the
telecommunications room, our MT-RJ Quick-Pack
™ adapter plates fit into our
popular line of RIC3, SWIC3, and FCP3 fibre enclosures.
MT-RJ CONNECTOR PRODUCTS
The Siemon MT-RJ Field Termination Kit (FTERM-
MT) is used to terminate connectors in the field
Higher density — MT-RJ connectors are one-third
the size of duplex SC connectors, providing
significantly higher density
MT-RJ MAX Modules with MT-RJ Jumper
Proven no epoxy/no polish termination
method terminates in less than 2 minutes —
less than 1 minute per fibre
Optical performance meets
ANSI/TIA/EIA-568-B.3 and
ISO/IEC 11801 Ed 2.0
requirements
Two boots are included to enable
termination of either 3.0mm
round duplex cable or 900µm
buffered fibre
Snagless latch — MT-RJ
connectors use the familiar “RJ”
style latch found on modular plugs
Factory-polished connectors assure
optimum performance and reliability
