Targus Wi-Fi ® Mouse
10
Targus Wi-Fi ® Mouse
11
If the mouse is not used for an extended period of time, it will automatically en-
ter power saving mode to conserve power and increase the battery life. Click
on any mouse button to resume the normal operation. The mouse may take a
few seconds to reconnect with your computer. To extend the life of your bat-
tery, turn the mouse off while travelling or when not in use.
Battery Indicator
• When the mouse is powered on, the blue light will turn
on and fade out in 2 seconds
• Wi-Fi Connection: Blue light will flash 2 times per
second
• Pairing: Blue light will flash once per second when the
pairing button is held for over 1 second
• Low-Battery Warning: An amber colored light will flash
once per second
When the mouse is switched on, the
battery indicator light will light up:
Power Saving Mode
Mouse Keys and Functions
1 Left Mouse Click Left Mouse Click
2 Right Mouse Click Right Mouse Click
3 Left Side Button Internet Page Backward
4 Right Side Button Internet Page Forward
5 Scroll Wheel
Will scroll the page horizontally. When moved from side to
side the Tilt Wheel will scroll the page vertically (tilt wheel
function is defined by the program you are using)
6
Battery Indicator/
Windows Task Switching
Button
See “DPI Setting and Indication” and “Windows 7 Task
Switching Sections”
7 Pairing Button Press to pair the mouse with your computer
8 Power Button Slide the power button to switch the mouse on/off
1
3
6
5
2
4
7
8
