Transcend Information USB2.0 Internal Multi-Card Reader TS0MFLRD8B User Manual
Page 2
T
T
T
S
S
S
0
0
0
M
M
M
F
F
F
L
L
L
R
R
R
D
D
D
8
8
8
B
B
B
USB2.0 Internal Multi-Card Reader
Transcend Information, Inc.
2
Block Diagram
Pinouts
Pin No.
Pin Name
01 VCC
02 USB-
03 USB+
04 VSS
05
NC / SG
Pin Identification
Symbol
Function
USB-
USB+
USB differential signal:
The pairs are used to transmit
Data/Address/Command
VSS Ground
VCC USB
Power
Input
NC / SG
Not Connect / Shield Ground
