Using The TPA0242 EVM Stand-Alone
3-17
Details
3.4.2
TPA0242 EVM Connected for Single-Ended Output
Figure 3–10. TPA0242 EVM Connected for Stereo Single-Ended Output
33
µ
F –
1000
µ
F
+
+
33
µ
F –
1000
µ
F
Audio
Input
(Right)
Audio
Input
(Left)
5 V
GND
ROUT+
ROUT–
SE/BTL
S1
SHUTDOWN
GND
LOUT–
LOUT+
C11
C2
C13
VDD
GND
L IN+
GND
L LINE–
L HP
VDD
GND
R HP
R LINE–
GND
R IN+
C10
+
TPA00242 EVM Board
SLOP275
U1
+
TEXAS
INSTRUMENTS
R2
R1
PCBEEP
C1
C12
C6
C5
C4
R3
S2
C7
C8
C9
C3
SHUTDOWN
R4
S3
S4
HP/LINE
Table 3–3. Typical TPA0242 EVM Jumper Settings for Single-Ended Stand-Alone
EVM
S3
TPA0242
ON
Note:
ON = Shunt installed
OFF = Open
