Product Brief: Belleta® iPB Series – Surface Mount PicoBrick
©2003-2005 TDK Innoveta Inc.
iPBProductBrief060805.doc 6/8/2005
℡
(877) 498-0099
2/2
Dimensions are in mm [inches]
Ordering Information
Product
Identifier
Package
Size
Platform
Input
Voltage
Output
Current/
Power
Output
Units
Main
Output
Voltage
# of
Outputs
Safety
Class
Feature Set
i P
B
48
010
A
033
V
-
0
01
050 – 5V
033 – 3.3V
025 – 2.5V
018 – 1.8V
TDK Innoveta
Picobrick
Belleta SMT
36-75V
007 – 7
010 – 10
Amps
015 – 1.5V
Single
01 – Standard
PIN
FUNCTION
PIN
FUNCTION
1
Vout (+)
4
On/Off
2
Vout (-)
5
Vin (-)
3
Vout Trim
6
Vin (+)
Top view - Footprint
1 2 3
4
5
6
3320 Matrix Drive Suite 100
Richardson, Texas 75082
Phone (877) 498-0099 Toll Free
(469) 916-4747
Fax (877) 498-0143 Toll Free
(214) 239-3101
Information furnished by TDK Innoveta is believed to be accurate and reliable. However, TDK Innoveta assumes no
responsibility for its use, nor for any infringement of patents or other rights of third parties, which may result from its use. No
license is granted by implication or otherwise under any patent or patent rights of TDK Innoveta. TDK Innoveta components
are not designed to be used in applications, such as life support systems, wherein failure or malfunction could result in injury
or death. All sales are subject to TDK Innoveta’s Terms and Conditions of Sale, which are available upon request.
Specifications are subject to change without notice.
