Product Summary
The B114-0H4 splitter allows a single SVGA source to be split and displayed on up to four
monitors simultaneously up to 210 ft. away.
Product Features
• Power consumption: 5V (0.5 Amp)
• Supports bandwidths up to 450 MHz
• Supports resolutions up to 2048 x 1536
Package Contents
• B114-0H4 SVGA 1-to-4 splitter
• AC adapter
• Owner’s Manual
Installation
1. Connect the SVGA cable between the SVGA source and B114-0H4 splitter marked ‘INPUT’.
