Adjustable Hinge ProEdge™ – Features
& Benefits
Tilt Top ‘in and out’ or Bottom ‘in and out’ adjustment
„ Correct for ‘out of plumb’ condition
Up and down adjustment of 5/16” (5/8” total) in either direction
„
Allows for an ideal fit between door bottom and sill, and top of door
and frame header
‘In and out’ adjustment from door frame stop of 1/8” in either
direction (1/4” total)
„ Permits ideal fit, sealing and operation between door and weatherstrip
and frame keeper for maximum performance
)
EASY adjustability in the field for
installer
Section 1-6
