1 1 F T. C O M M E R C I A L C A N T I L E V E R U M B R E L L A
IMPORTANT PARTS AND NAMES
Base Shell Base Lid
(1)
(7)
(6)
(9)
(10)
(8)
(5)
(4)
(3)
(2)
(11)
1. Base Shell and Base Lid 7. Tilt Lever
2. 360 o Rotating Hub 8. Tilt Degree Scale
3. Base Pedal 9. Canopy Support Beam
4. Crank Lift Handle
10. Canopy
5. Main Frame Stand 11. Valance
6. Main Frame Grip
