10. SPECIFICATIONS
533-06-067-00
Enclosure Type Acoustic Super Woofer system
Power Handling Continuous program: 240 W (40 – 200 Hz)
Continuous pink noise: 80 W (40 – 200 Hz)
Rated Impedance 8
Ω
Sound Pressure Level 91 dB (1W, 1m), installation in 1/2 free sound field
85 dB (1 W, 1m), installation in free sound field
Frequency Response 45 – 200 Hz (–10 dB, installation in 1/2 free sound field)
Speaker Element 20 cm cone type
Input Terminal Detachable screw terminal, (+)/(–): 2 each (for bridge connection)
Usable Cable Solid or stranded cable: 0.2 – 2.5 mm 2 (corresponding to AWG24 – 14)
Finish Enclosure Rolled steel plate, black, paint
Front Grille Rolled steel plate, white, paint
Grille Frame Fire-resistant ABS resin (UL 94V-0), white, paint
Mounting bracket Rolled steel plate, black, paint
Dimensions 430 (w) x 544 (h) x 135 (d) mm
Weight 11 kg (front grille and mounting bracket excluded)
Optional Matching Transformer MT-S0601 (rated at 60 W)
Note: The design and specifications are subject to change without notice for improvement.
• Accessories
Mounting bracket .................................................. 1
Front grille ............................................................ 1
Anchor piece ........................................................ 2
Stud holder ........................................................... 4
Pattern paper ....................................................... 1
Masking tape (long and short) ..................... 2 each
Mounting screws
M5x10 (for anchor piece) ................................. 4
3x8 (for stud holder) ......................................... 4
M4x30 with plain and spring washers .............. 6
Spring washer (M5 for anchor piece) ............... 4
Plain washer (M5 for anchor piece) ................. 4
