Setting up your computer and getting started
5.375 x 8.375 ver 3.1
11 Pick up the memory module by its sides, avoiding any
contact with its connector. Position the module toward
the socket, aligning the connector’s notch with the
matching key in the socket.
(Sample Illustration) Aligning the memory module with the socket
12 Firmly press the memory module into the memory slot’s
socket at approximately a 30-degree angle (to the
horizontal surface of the computer).
(Sample Illustration) Inserting the module in the socket
latch
latch
key
notch
connector
