2-1 Quick Start
Quick Start
The steps in this chapter can be followed to quickly prepare the TPA6011A4
audio amplifier EVM for use. Using the TPA6011A4 with the TI plug-n-play
audio amplifier evaluation platform is a quick and easy way to connect power,
signal and control inputs, and signal outputs to the EVM using standard
connectors. However, the audio amplifier evaluation module can be used
stand-alone by making connections directly to the module pins, and can be
wired directly into existing circuits or equipment.
The platform switch and jumper settings shown in Table 2–1 are typical for the
TPA6011A4 EVM and will cause the TPA6011A4 to switch to single-ended out-
put mode when a plug is inserted into platform headphone jack J10.
Table 2–1. Typical TI Plug-N-Play Platform Jumper and Switch Settings for the
TPA6011A4
EVM JP6 JP7 JP8 S2 S3
P-N-P Platform Mode X Hi Note 2 U2–U4
Notes: 1) X = Don’t care
2) Set S2 to ON when signal conditioning board is installed in U1; set S2
to OFF when no signal conditioning board is installed.
Table 2–2. Typical TPA6011A4 EVM Jumper Settings
EVM J1 J2 J3 J4
TPA6011A4 OFF OFF ON OFF
Note: ON = Shunt installed
OFF = Open
Topic Page
2.1 Precautions 2–2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.2 Quick Start List for Platform 2–3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.3 Quick Start List for Stand-Alone 2–5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 2
