Tunturi C4 User Manual
Page 10
58
1
103 7040
Base frame
1
2
173 7011
Chain cover, left
1
3
173 7012
Chain cover, right
1
4
533 7041
Turning plate cover
2
5
103 7041
Front foot
1
*6
M8x90 DIN 603
Screw
4
7
533 7042
Front foot cover
2
*8
M8 DIN 137A
Washer
10
*9
M8 DIN 127
Spring washer
16
*10 M8 DIN 1587
Cap nut
4
11 103 7042
Rear foot
1
12 533 7051
Rear foot cover
2
13 403 7033
Sensor wire
1
14 403 7035
Cable set
1
15 403 7034
Servo motor
1
16 M8x25 ISO 7380
Screw
2
17 513 7016
Macgnetic bow bracket
1
19 203 7025
Upright tube, (incl. 36)
1
*20 653
7029
Screw
6
21 523
9006
Bearing
8
22 103 7043
Pedal tube, right (incl. 21)
1
23 M8 DIN 125
Washer
2
24 M8x20 ISO 7380
Screw
4
25 363 7005
Pedal, pair (incl. 35)
1
*26 M6x60 DIN 603
Screw
4
*27 M6 DIN 125
Washer
11
*28 M6 DIN 127
Spring washer
8
*29 653 7022
Knob dawl
4
30 203 7037
Swivel tube, EUR (incl. 21) 2
-
203 7029
Swivel tube, USA (incl. 21) 2
31 653 7025
Washer
2
32 343 7022
Pedal tube shaft
2
33 533 7043
End cap
2
34 103 7044
Pedal tube, left (incl 21)
1
36 533 7044
Plug axle support
6
*37 503 7015
Fix handlebar bracket
1
38 343 7019
Axle support
1
39 203 7026
Handle bar, RH, EUR
1
-
203 7030
Handle bar, RH, USA
1
(incl. 36,40,42,43)
40 533 7045
Plastic insert
2
41 203 7027
Handle bar, LH, EUR
1
-
203 7031
Handle bar, LH, USA
1
(incl. 36,40,42,43)
42 213 7008
Handle grip, pair
2
43 533 7047
Handlebar end cap
2
*44 M8 DIN 440
Washer M8 OD 28mm
2
45 233 7015
Computer (incl. 45a, 45b)
1
45a 423
7057
Membrane
1
45b 173 1065
Meter lower cover
1
-
M3x8 DIN 7504 M Screw
6
46 M5x10 DIN 7985
Screw
4
47 203 7028
Fix handlebar (incl.48,83,84) 1
48 403 7032
Pulse grip unit (incl.49)
2
*50 653 7023
Spring knob, EUR
2
* -
653 7032
Screw, USA
2
*51 653
7030
Screw
4
52 503 7017
Sensor bracket
1
53 Mx12 DIN 7985
Screw
2
54 523 409 85
Bearing
4
55 17 DIN 417
Clip C17
3
56 343 7020
Axle for pulley
1
57 263 7007
Pulley (incl. 80)
1
58 503 7011
Safe bracket
1
59 M6x18 DIN 933
Screw
4
60 M6 DIN 985
Nylock nut
4
61 513 7001
Bracket (incl. 54, 55)
1
62 643 7001
Carge spring
1
63 523 7014
Spacer sleeve
3
64 M6x14 DIN 933
Screw
3
65 373 7006
Magnetic bow
1
66 M8x52 DIN 931
Screw
1
67 M8 DIN 985
Nylock nut
1
68 223 7005
Metal wire
1
69 M6x10 DIN 7985
Screw
6
70 643 7002
Spring
1
71 403 7020 EU
Mains cable/transformer
1
-
403 7020 GB
Mains cable/transformer
1
-
403 7020 USA
Mains cable/transformer
1
-
403 7020 JPN
Mains cable/transformer
1
-
403 7020 AUS
Mains cable/transformer
1
72 303 7002
Flywheel (incl.73-75,77,78) 1
73 523 504 84
Bearing
2
74 343 7021
Flywheel axle
1
75 12 DIN 471
Clip C12
2
76 443 7003
Belt
1
77 M10 DIN 125
Washer
2
78 653 7026
3/8” Wh nut
2
79 433 7007
Turning pedal, right
1
80 403 7017
Magnet
1
81 433 7008
Turning pedal, left
1
82 M8x16 DIN 933
Screw
2
83 533 7046
Fix handlebar end cap
2
84 213 7009
Fix handlebar grip
1
85 M6x15 DIN 7985
Screw
1
86 M6 DIN 985
Nylock nut
1
87 503 7018
Keep back bracket
1
88 503 7019
Spring bracket
1
89 533
7052
Washer
2
-
423 7052
Lable set
1
-
553 7006
Assembly kit (incl *)
1
-
583 7010
Owner’s manual
1
