10. SPECIFICATIONS
• Accessories
Adapter Panel
Pattern paper
Speaker mounting screw
M4 x 25 (with spring washer and
plain washer)
Electrical box mounting screw
M4 x 25
UNC No. 8-32 x 32 mm
Spring washer
Plain washer
Printed in Japan
133-01-413-2A
TOA Corporation
*
1
Continuous 24 hours, band-limited pink noise (50 to 20,000 Hz)
*
2
Pink noise (1,000 Hz to 10,000 Hz)
Note : The design and specifications are subject to change without notice for improvement.
Enclosure Type
Power Handling
Rated Input
Rated Impedance
Output Sound Pressure Level
Frequency Response
Crossover Frequency
Speaker Element
Input Terminal
Usable Cable
Material and Finish
Dimensions
Weight
Sealed type
90 W (continuous program input, 4
loaded)
30 W (continuous pink noise input, 4
loaded)*
1
12 W (16
or high impedance)
4
, 16
70V line: 420
(12 W), 830
(6 W), 1.7k
(3 W), 3.3k
(1.5 W)
100 V line: 830
(12 W), 1.7 k
(6 W), 3.3 k
(3 W)
85dB(1W, 1m, 2
loading)*
2
120 Hz to 20 kHz (— 10 dB, 2 loading)
5,000 Hz
Low frequency: 8 cm x 5 cm cone woofer (neodymium magnet)
High frequency: Balanced dome tweeter
Detachable screw terminal, (+)/(-) 2 each (for bridging connection)
Solid cable or stranded cable: 0.2 mm
2
- 2.5 mm
2
(Corresponding to
AWG No. 24-14)
Enclosure:
Fire-resistant ABS resin (UL 94V-0), black
Trim Piece:
Fire-resistant ABS resin (UL 94V-0), white
Grille:
Rolled steel plate, white, paint
Adapter Panel: Stainless steel
312(w) x 126(h) x 90(d) mm
1 .5 kg (including Adapter Panel)
