Tripp Lite SNMPWEBCARD User Manual
Model #: snmpwebcard
Tripp Lite
1111 West 35th Street
Chicago, IL 60609 USA
Telephone: +(773) 869 1234
Model #: SNMPWEBCARD
For remote monitoring and control via SNMP, Web or Telnet
Highlights
NEW firmware web-only version 12.06.0061 now available!
Internal SNMP/Web management accessory card
Provides remote monitoring and control of UPS systems and power conditions
Network Time Protocol support for automatic updates to the card's real-time
clock from an NTP server
Compatible with any expansion slot-equipped Tripp Lite UPS System
Simple installation and setup
Description
Tripp Lite's SNMPWEBCARD gives IT managers better visibility and control in high-density network environments. It enables any expansion
slot-equipped Tripp Lite SmartPro or SmartOnline UPS System to be operated as a managed device on the network. The SNMPWEBCARD employs
the SNMP network to remotely monitor and control UPS systems and site electrical conditions via a management platform or web browser. The
SNMPWEBCARD can provide remote viewing of site electrical data, UPS status information and self-test logs. When used with Tripp Lite UPS
systems equipped with load management receptacles, it can remotely reboot locked-up network devices without interrupting power to other critical
loads. An optional ENVIROSENSE accessory module provides remote temperature/humidity monitoring and a dry contact interface to control and
monitor alarm, security and telecom devices. The SNMPWEBCARD comes with a 2-year warranty. NEW firmware web-only version 12.06.0061 now
available! - supports IPv6, Radius, and secure file transfer. Firmware is not applicable with cards running firmware version 12.04.0047 or earlier.
NOTE: Existing 12.04.0048 and 12.04.0049 cards must be upgraded to the 12.04.0055 firmware prior to upgrading to 12.06.0061.
Applications
Ideal for remote management and control of UPS and power data in LAN/WAN racks, computer rooms and data center environments
System Requirements
Tripp Lite UPS/PDU with SNMPWEBCARD running Version 12.04.0055
FTP utility
Web browser
Jave Runtime Environment 1.6.026 or later
NOTE: Existing 12.04.0048 and 12.04.0049 cards can be upgraded to the 12.04.0055 firmware to provide SNMPv3 support, then to
12.06.0061 for IPv6 support. Firmware is not applicable with cards running firmware version 12.04.0047 or earlier.
Package Includes
SNMPWEBCARD
Quick Start Installation Guide
Configuration Cable
Software CD including Owner's Manual & MIB files
Cover Plates (secures card in UPS system's SNMP accessory slot)
Features
Enhanced UPS Management and Control: The SNMPWEBCARD makes any slot-equipped Tripp Lite UPS a managed device on the network,
controllable via SNMP network management platforms or a web browser. This enables IT managers to remotely monitor current site electrical data,
UPS self-test and alert logs, as well as logged power events such as blackouts, brownouts, overvoltages, and other electrical problems. When used
with the customized load management receptacles available on select Tripp Lite UPS systems, the SNMPWEBCARD also support selective
rebooting of locked-up network equipment without disrupting power to other mission-critical loads.
