WORLDWIDE EXCLUSIVITY
Filtration, drainage and automatic
storage of oil/fat
Oléoclean is fitted with an exclusive and
patented system for filtration and automatic
drainage, suitable for most types of oils
and fats used for cooking.
Thanks to the OIL BOX container, you
can store your oil or fat and keep it until
you next want to use it.
- The drainage of oil is completely
automatic and does not need any special
handling, which makes it totally safe.
- Thanks to the automatic filtration
system, your oil/fat stays clean and lasts
longer for healthier frying.
- Separate OIL BOX containers can be
used to store oil/fat used for frying
different types of food (chips, fish,
doughnuts, etc.) to avoid any transfer of
flavours.
Dismantling the fryer
Open the lid by pressing on one of the two
buttons and pull it away from the fryer
- Fig.
Remove the oil/fat container - Fig.
Lift the basket handle until you hear a
“click” as it locks - Fig.
Remove the basket.
After pulling the cord towards the front,
remove the control panel - Fig.
Take out the bowl from the housing.
Unscrew (1) the drain valve located on the
bottom of the bowl.
Remove the drain valve
(2) and filter grid
(3) - Fig.
Preparation for use
Cleaning the fryer
Remove the protective film from the
underside of the viewing window
(depending on model).
Clean all parts (except the control panel)
with a sponge and washing-up liquid or
put them through the dishwasher - Fig.
Dry them off.
For good visibility through the
window, see chapiter Cleaning.
Never immerse the control panel
and cord in water.
Ensure that the anti-odour filter is
dry before frying.
Reassembling the fryer
Important : while replacing the automatic
drain valve ensure that the seal is placed
correctly under the 3 lugs designed for this
purpose.
Place the filter grid in the bowl (domed
side facing you) - Fig.
Turn the bowl over holding the filter grid.
Place
(1) the automatic drain valve flat on
position O.
Turn
(2) to position I - Fig.
Replace the bowl then the control panel.
8
7
6
5
4
3
2
1
Description
1 Lid
2 Viewing window
3a Anti-odour carbon filter
3b Filter handling tabs
4 Basket
5 Basket release button
6 Handle for raising and lowering basket
7 Non-stick removable bowl
8 Bowl fill level marks (1L/2L)
9a Filter grid
9b Automatic drain valve
10 Housing
11 Cord holder
12 Lid opening buttons
13 Carrying handles when cold
14 Container fill tube
15 Container lid cap (for emptying)
16 “OIL BOX” oil/fat container
17 Drain button
18 Plug with cord
19 Control panel
20 Temperature light
21 Thermostat
