LANMaster™ T8 8-Port Ethernet™ Repeater Hub 14 5
Powering the LANMaster T8
To power ON the LANMaster T8:
1. Verify that the LANMaster T8 power supply adapter is the
correct one for the site installation.
2. At LANMaster T8 back, locate the power receptacle.
3. Connect the LANMaster T8 power connector end of the
power supply adapter to LANMaster T8 power receptacle.
4. Plug external power connector end (male) of the power
supply adapter into correct voltage AC wall socket.
5. At LANMaster T8 front, verify that Act(ivity) LED is
illuminated.
3. INSTALLATION
To install the LANMaster T8:
• Unpack the LANMaster T8
•
Install LANMaster T8 at site
• Install Network Cable
• Power the LANMaster T8.
Direction is provided in the pages that follow.
Unpacking the LANMaster T8
The LANMaster T8 packing contents should include the following:
Item Part Number
LANMaster T8 Hub E-TBT-HB-0804
(includes mounting brackets and screws,
BNC T-connector and terminator, and
adhesive-backed rubber feet)
Power Supply Adapter 3532, 3533, 3534, 3535, or 3536
(depending upon power configuration
in country where installed)
User’s Guide 33022
