Therma-Stor Products Group Quiet-Vent Ventilation System User Manual
Page 2
Table of Contents
1. Specifications .............................................................1
2. Installation ..................................................................1
2.1 Back-Drafting Open Combustion Devices ..............1
2.2 Location of the Ultra-Aire Quiet Vent ......................2
2.3 Fresh Air Inlets ......................................................3
2.4 Hanging the Ultra-Aire Quiet Vent ..........................3
2.5 Ducting to and from the Ultra-Aire Quiet Vent ........3
2.6 Wiring the Ultra-Aire Quiet Vent .............................3
3. Operation ....................................................................4
3.1 Using the Timers ...................................................4
3.2 Adjusting the Amount of Ventilation .......................4
4. Maintenance ...............................................................4
4.1 Cleaning the Blower Screen ..................................4
5. Service .......................................................................4
5.1 Circuit Breaker Trips ..............................................4
5.2 Blower Operates on One Speed Only .....................5
5.3 7-Day Timer Does Not Advance .............................5
5.4 Fan Motor .............................................................5
5.5 Warranty ...............................................................5
6. Service Parts List ........................................................5
7. Warranty .....................................................................6
Read and Save These Instructions
WARNING!
— This symbol indicates important
instructions. Failure to heed them can result in serious
injury or death.
CAUTION!
— This symbol indicates important
instructions. Failure to heed them can result in injury or
material property damage.
1. Specifications
Model:
Ultra-Aire Quiet Vent
Part Number:
4019663
Electrical Specs:
110-120Vac, 60Hz, 1ph
Max HACR Type
Circuit Breaker or Fuse: 10A
Blower:
0.65 Amps, Thermally Protected
Capacitor:
370 VAC, 6 MFD
2. Installation
WARNING: To reduce the risk of fire,
electric shock, or injury to persons, observe
the following:
A. Installation work and electrical wiring must be done by
qualified person(s) in accordance with all applicable
codes and standards, including fire-rated construction.
B. Sufficient air is needed for proper combustion and
exhausting of gases through the flue (chimney) of fuel
burning equipment to prevent backdrafting. Follow the
heating equipment manufacturer’s guideline and safety
standards such as those published by the National Fire
Protection Association (NFPA), and the American Society
for Heating, Refrigeration and Air Conditioning Engineers
(ASHRAE), and the local code authorities.
C. When cutting or drilling into wall or ceiling, do not
damage electrical wiring and other hidden utilities.
D. Ducted fans must always be vented to the outdoors.
E. If this unit is to be installed over a tub or shower, it must
be marked as appropriate for the application.
F. NEVER place a switch where it can be reached from a tub
or shower.
2.1 Back-Drafting Open Combustion Devices
CAUTION: Do not use open combustion
heating appliances (unless equipped with
power exhaust) in a home equipped with
exhaust fans (i.e., bath fans, kitchen hoods,
down draft stoves, or the Ultra-Aire Quiet
TABLE OF CONTENTS
2
Ultra-Aire Quiet Vent Installer’s & Owner’s Manual
