5-in-1 PC Card Adapter
Transcend Information Inc.
✁
68Pins Pinouts
Pin
No.
Pin
Name
Pin
No.
Pin
Name
Pin
No.
Pin
Name
Pin
No.
Pin
Name
01 GND 18 RFU 35 GND 52 RFU
02 D3 19 RFU 36 /CD1 53 RFU
03 D4 20 RFU 37 D11 54 RFU
04 D5 21 RFU 38 D12 55 RFU
05 D6 22 A7 39 D13 56 RFU
06 D7 23 A6 40 D14 57 RFU
07 /CE1 24 A5 41 D15 58 RST
08 A10 25 A4 42 /CE2 59 /WAIT
09 /OE 26 A3 43 RFU 60 RFU
10 RFU 27 A2 44 /IORD 61 /REG
11 A9 28 A1 45 /IOWR 62 SPKR
12 A8 29 A0 46 RFU 63 /STSG
13 RFU 30 D0 47 RFU 64 D8
14 RFU 31 D1 48 RFU 65 D9
15 /WE 32 D2 49 RFU 66 D10
16 /IRQ 33 /IO16 50 RFU 67 /CD2
17 VDD 34 GND 51 VDD 68 GND
Recommended
✂ ✄ ☎ ✆
✝ ✞ ✟ ✠ ✡ ☛ ☞ ✠ ✌ ✟ ✞✟ ☞ ✠ ✍
Parameter Min. Typical Max.
Power Supply Voltage (VDD) 4.5V 5V 5.5V
Operating Temperature 0
✎
60
✎
Storage Temperature -20
✎
85
✎
Humidity 8% ~ 95% RH
Above technical information is based on industry standard data and tested to be reliable. However, Transcend makes no
warranty, either expressed or implied, as to its accuracy and assumes no liability in connection with the use of this
product. Transcend reserves the right to make changes in specifications at any time without prior notice.
