1

1 - Characteristics

Diameter of Pressure Cooker base:

Technical informations:
Maximum operating pressure: 55 kPa (8 psi).
Maximum safety pressure: 110 kPa (16 psi).

Compatible heat sources

Stainless steel models can be

used on all hob types, including

induction.

On an electric hob, use a hotplate of a diameter

equal to or less than the diameter of the base of the
Pressure Cooker.

On a ceramic hob, take care that the bottom of the

pan is perfectly clean.

On gas, the flame should not go beyond the base of

the pan.

TEFAL accessories

For other spare parts or repairs contact TEFAL

After Sales Service (See enclosed list).

Use only the appropriate TEFAL spare parts for

your model.

2 - Closing

Turn the tightening knob to the left to lower the

clamp.

Slide the lid horizontally onto the rim of the

Pressure Cooker, making sure it sits properly on the
pan - Fig 1

Turn the tightening knob to the right until the clamp

is in contact with the clamp hook on the Pressure
Cooker - Fig 2

To ensure that the lid is locked into position, turn

the tightening knob again through (two complete
turns mimimun).

3 - Opening

Turn the tightening knob to the left to lower the

clamp - Fig 3

Lift the lid to release it.

Slide it horizontally away from the pan - Fig 4

4 - Filling

Minimum 25 cl (2 small cupfuls) - Fig 5
Maximum
- Do not fill the unit over 2/3 full - Fig 6

For steam cooking

Use at least 75 cl of liquid.

Suspend the basket from the rivets on the pan - Fig 7

For certain foods

For foods which expand during cooking, such as

rice, dehydrated vegetables, or compotes, do not fill
your Pressure Cooker more than half full - Fig 8

5 - When using for the first time

Turn the pan upside down to fit the handles. Place

them in position, engage the screws and screw them
up tightly.

After using for a few days, tighten the screws again.

Place the pressure regulator valve on the steam

outlet and align one of the two symbols on the valve
with the valve position index. Press down fully - Fig 9

Turn to the “cook” position - Fig 10

Put the steaming basket in the base of the pan.

Fill 2/3 full with water.

Close the Pressure Cooker.

Place the Pressure Cooker on a source of heat at

high setting.

When steam begins to escape through the pressure

regulator valve, reduce the heat and wait 20 minutes
- Fig 11

When the 20 minutes are up, turn off the heat.

Reduce pressure by putting your Pressure Cooker

under the cold tap - Fig 12

When steam no longer comes from the pressure

regulator valve, turn the pressure regulator valve to the
steam release position and open the lid - Fig 13

GAS

SEALED (solid)

CERAMIC

HALOGEN

INDUCTION

Descriptive diagram

A - Pressure regulator valve
B - Tightening knob
C - Safety valve
D - Clamp
E - Steam outlet

+ pressure valve position

F - Gasket

G - Steaming basket (depending on model)
H - Rivets
I - Clamp Hook
J - Handle
K - Fixing screw
L - Pan

Stainless steel

Capacity

Base Ø

Models

4,5 L

18 cm

P05206

6 L

18 cm

P05207

8 L

18 cm

P05211

10 L

20 cm

P05216
