Quick Reference Guide
Notes:
1. To activate the OSD main menu, use the hotkey sequence ScrLk + ScrLk
+ (Space Bar). For detailed OSD operation reference, please refer to the
User Guide. When OSD Main Menu is active, the mouse will be locked until
the OSD Menu is off.
2. Note that a, b, y and z each denotes a number key. ab= 01 - 08 yz= 01
- 16. (e.g. ScrLk + ScrLk + 03 + 06 is for Bank 3, Port 6.) When using a
single KVM Switch configuration, the default Bank # is 01.
3. The password has an 8 character limit. If you forget your password and
can’t access your NetController KVM switch, contact Tripp Lite Tech
Support at (773) 869-1234.
4. User-Definable Hotkey Preceding sequence. OSD Setup Menu allows user
to choose between Scroll Lock, Caps Lock, Num Lock and F12.
5. Each hotkey in a hotkey sequence must be pressed within 2 seconds of
the preceding hotkey for the command to take place.
200806025 93-2760
QUICK REFERENCE SHEET for NetController KVM Switches—Hotkey and OSD Operating Commands
Hotkey Sequence 5 = [ScrLk] 4 + [ScrLk] 4 + Command key(s)
Warranty Registration
Visit www.tripplite.com/warranty today to register the warranty for
your new Tripp Lite product. You’ll be automatically entered into a
drawing for a chance to win a FREE Tripp Lite product!*
* No purchase necessary. Void where prohibited. Some restrictions apply. See website for
details.
Tripp Lite World Headquarters
1111 W. 35th Street, Chicago, IL 60609 USA
(773) 869-1234 • www.tripplite.com
Copyright © 2008 Tripp Lite. All rights reserved. The policy of Tripp Lite is
one of continuous improvement. Specifications are subject to change without
notice. Made in China.
Command Hotkey Sequence 5 OSD Control 1 Description
Select Computer ScrLk 4 + ScrLk 4 + ab + yz
(ab= 2-Digit Bank # yz= 2-Digit Channel #) 2
Highlight the desired computer and
hit the Enter key Activates a desired computer to be accessed via the console
(Shared USB or PS/2 Keyboard, Mouse and Monitor)
Next Lower Channel ScrLk 4 + ScrLk 4 + — Selects the next lower connected channel on the active KVM Switch
Next Higher Channel ScrLk 4 + ScrLk 4 + — Selects the next higher connected channel on the active KVM Switch
Next Lower Bank ScrLk 4 + ScrLk 4 + PgUp Hit Page Up button when in OSD Main Menu Select the next lower KVM Switch in a Daisy-Chain
Next Higher Bank ScrLk 4 + ScrLk 4 + PgDn Hit Page Down when in OSD Main Menu Select the next higher KVM Switch in a Daisy-Chain
Beep On/Off ScrLk 4 + ScrLk 4 + B — Turns the beep sound on/off when Auto Scanning and when hitting hotkeys
Auto Scan ScrLk 4 + ScrLk 4 + S — Starts an Auto Scan of all the connected computers
Stop Autoscan Any key — Stops an Auto Scan of all the connected computers
Title Bar On/Off ScrLk 4 + ScrLk 4 + T — Turns the Title Bar On/Off
Reset Console Mouse
& Keyboard
ScrLk 4 + ScrLk 4 + End — Resets Console Mouse & Keyboard in the unlikely event of a lockup
Show OSD Main Menu ScrLk 4 + ScrLk 4 + (Space Bar) — Opens up the OSD Main Menu
Change Computer
Name
— Highlight the desired computer in the OSD
Main Menu, hit Insert to change name Changes the computer’s name from the default (PC01, PC02, etc)
to a user-defined name. 8 character limit
Load Default — In OSD Setup Menu select Load Default and hit
the Enter Key Restores all settings (Auto Logout, OSD Timeout, etc.) on all daisy-chained
KVM switches to the default settings. Does not affect password
OSD Appearance — In OSD Setup Menu highlight OSD Appearance
and use Keys to choose Yes/No Specifies if you want to keep/hide the OSD Menu after a Port Switching
Operation
Auto Scan Period
(00 – 95 seconds) — In OSD Setup Menu highlight Auto Scan Period
and use the keys to choose time interval Specifies a time interval for the Auto Scan to switch between computers.
Auto Scan set to 10 seconds by default. 00= Disabled
Auto Logout Timeout
(00-99 minutes) — In OSD Setup Menu highlight Auto Logout and
use the keys to choose time interval Specifies the amount of time that must pass without keyboard activity before
KVM logs off. This requires password to be entered to access KVM. Auto
Logout is disabled by default: 00= Disabled
OSD Menu Timeout
(00-95 seconds)
— In OSD Setup Menu highlight OSD Timeout and
use the keys to choose time interval Specifies the amount of time with no activity before the OSD Menu turns off.
OSD Menu Timeout defaults at 30 seconds
Title Bar Position — In OSD Setup Menu highlight Title Bar; use
keys to choose Left, Right or Disable Displays the Title Bar on the Left or Right side of the monitor screen or
disables it
Password 3 — In OSD Setup Menu highlight Password and hit
the Enter key; follow steps to set password Enables/disables the password for the B040-004, -008 or -016 KVM switch.
User-definable password has an 8-character limit
Define Hotkey
Preceding Sequence
— In OSD Setup Menu highlight the Hotkey Option;
use keys to select desired Hotkey Selects a Hotkey preceding sequence of Scroll Lock, Caps Lock,
Num Lock or F12
