PARTS INFORMATION
[email protected] Page 13
TPH-260PF
GEAR CASE • FIGURE 9
ITEM PART NUMBER DESCRIPTION QTY COMMENTS
9-1 3003228721 CASE,GEAR,A,24mm 1
9-3 99961690101 BEARING,BALL,#6901ZZ 2
9-4 99352012002 RING,STOP,S12,OUTER 1
9-5 99351024002 RING,STOP,C-24,IN 1
9-6 99961608013 BEARING,BALL,#608Z 1
9-7 99351022002 RING,STOP,C22,IN 1
9-8 30032250801 FITTING,GREASE 3
9-11 99051050103 BOLT,HEX.HOLE,5X10 1
9-12 99461050254 BOLT,HEX HOLE,5X25S 1
9-13 99053060125 SCREW,HEX HOLE 6X12 2
9-14 87132600200 WASHER,SPECIAL,B 2
9-15 3013228620 CASE,GEAR B 1
9-16 99961600014 BEARING,BALL,#6000DD 1
9-17 99351026002 RING,STOP,IN,C-26 1
9-19 99355060000 RING,STOP,E6 1
9-20 3273228020 COVER,GEAR CASE A 1
9-22 99051040085 BOLT,HEX,4x8 2
9-23 99961608013 BEARING,BALL,#608Z 1
9-24 99351022002 RING,STOP,C22,IN 1
9-26 2103228620 HANDLE 1
9-29 99053060153 BOLT,HEX,6X15 2
9-30 0883228720 SEAL,D 1
9-35 3023228602 GEAR & PINION SET 1
9-36 5123228680 KNOB,HANDLE,A 1
9-41 99023060141 BOLT,PLUS,6X14 1
9-42 99187060001 NUT 2
9-43 4623228620 PLATE,SUPPORT 1
9-44 0863228620 SEAL,GREASE,B 1
9-45 99201060011 WASHER,6 2
