(1) When SW5=ON and SW6=ON, the VGA and SVGA resolutions are selected in
control panel/monitor.
(2) When SW1=ON, SW5=ON and SW6=ON, the VGA and SVGA resolutions are
selected in control panel/monitor.
5. Select the keyboard mode by setting DIP Switch 7:
Set SW7 = ON for a PS/2 101 Keyboard
Set SW7 =OFF for a PS/2 104 Keyboard
Figures 3 to 5 are the keyboard maps of the layouts for the different types of
keyboards. The keyboard mapping for the Mac keyboard to either the PS/2 101 or
104 keyboards is summarized in Table 2.
Table 4: Mac Keyboard Emulation by PS/2 Keyboard
Mac 101 Key 104 Key
[Shift] L or R [Shift] L or R [Shift]
[Ctrl] L [Ctrl] L or R [Ctrl]
[Option] R [Ctrl] L or R á
a L or R [Alt] L or R [Alt]
F13 [Print Scrn] [Print Scrn]
F14 [Scroll Lock] [Scroll Lock]
F15 L or R [Shift] and [Pause] L or R [Shift] and [Pause]
= [Pause] [Pause]
Power ON/OFF Power Key on Converter Power Key on Converter
[Return] [Enter] [Enter]
[Delete] Н Н
[help] [Insert] [Insert]
6. Select the mouse speed setting by setting DIP Switch 8:
Set SW8 = ON for high Speed
Set SW8 =OFF for Normal Speed
7. Press Converter’s POWER ON/OFF key to turn on the Mac.
Figure 3: Mac Standard Keyboard Setting
Figure 4: PS/2 101-Key Keyboard map for Mac Keyboard
Figure 5: PS/2 104-Key Keyboard map for Mac Keyboard
FCC Radio / TV Interference Notice
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy, and if not installed and used in accordance with the instruction
manual, may cause interference to radio communications. However, there is no guarantee that interference will not occur in a
