TANDBERG 770/880/990 MXP
174
5.5.4 Stereo Settings
Settings Output response
Out 1
Mode* Stereo input
mode Stereo
Speakers Audio out 1 Audio out 2
Analog Off Off Loudspeaker
mono VCR
Analog Off On Loudspeaker
left Loudspeaker
right
Analog On Off Loudspeaker
mono VCR
Analog On On Loudspeaker
left Loudspeaker
right
SPDIF Off Off Loudspeaker
mono VCR
SPDIF Off On Loudspeaker
L+R** VCR
SPDIF On Off Loudspeaker
mono VCR
SPDIF On On Loudspeaker
L+R** VCR
*Out 1 mode: Auto/Analog/SPDIF is described in Outputs .
**L+R = Left + Right
When Stereo Speakers is Off, the output response will be a mono loudspeaker signal on Audio
out 1 and VCR on Audio out 2 regardless on the Out 1 Mode and Stereo Input mode settings.
In analog mode the Stereo Speaker On will provide a stereo loudspeaker signal on Audio out 1
and 2.
If Stereo input mode is Off, Audio out 2 will be a mix of audio input 3, microphones and the far
end (the received far end signal is either mono, or stereo that is summed left+right into mono in
near end codec). (Note that stereo speakers set to on in analog mode will provide a different
scheme, see table above for details)
If Stereo input mode is On, Audio out 2 will be a mix of the microphones and the far end. (Note
that stereo speakers set to on in analog mode will provide a different scheme, see table above for
details)
