Connecting an Audio Device

1 Plug your headphones or speakers into the green

3.5mm Audio Out (Headset) port on the USB hub.

2 Plug your microphone jack into the mono Audio In

(Microphone) port.

3 Connect the audio output from the back of your

computer to the back of the USB hub via the supplied
audio pass-through cable as shown below.

Audio Connection of USB 4-Port Hub and PC

NOTE: S

OME

COMPUTERS

NEED

TO

CONNECT

TO

EITHER

THE

L

INE

-O

UT

OR

THE

C

ENTER

-

OUT

CHANNEL

OF

A

SOUND

CARD

. C

ONSULT

THE

SOUND

CARD

MANUAL

FOR

INSTRUCTIONS

(

PROCEDURES

MAY

VARY

).

Audio-In
(Microphone)

Audio-Out
(Headset)

High Power
USB Port

USB Port

DC Jack

Mini-USB (Type B)

Headset / Speaker /

Microphone (pink)

Stereo (green)
